USSP202 SNR  L1 225 mm Bearing units

USSP202 SNR L1 225 mm Bearing units

B22 mmA516 mmGR1/8" H241 mms111 mmS6 mmSW2.5 mmC9.55 kNC04.78 kNT min.-20 °CT max.100 °CRecommended tightening torque for set screw3.5 NmDesignation of housingSP203-205/40- Designation of bearingUS202G2 Bearing numberUSSP202BrandSNRBore Diameter (mm)15d15 mms6 mmA21 mmB122 mmD124.6 mmH78 mmH141 mmL264 mmL1225 mmThread (G)R1/8"Weight1.6 KgBas…
Contact Us Now !

Product description

USSP202 SNR L1 225 mm Bearing units

B22 mm
A516 mm
GR1/8″
H241 mm
s111 mm
S6 mm
SW2.5 mm
C9.55 kN
C04.78 kN
T min.-20 °C
T max.100 °C
Recommended tightening torque for set screw3.5 Nm
Designation of housingSP203-205/40-
Designation of bearingUS202G2
Bearing numberUSSP202
BrandSNR
Bore Diameter (mm)15
d15 mm
s6 mm
A21 mm
B122 mm
D124.6 mm
H78 mm
H141 mm
L264 mm
L1225 mm
Thread (G)R1/8"
Weight1.6 Kg
Basic dynamic load rating (C)9.55 kN
