UST205 SNR A 32 mm  Bearing units

UST205 SNR A 32 mm Bearing units

A224 mmB27 mmA519.5 mmGM6x1 H251 mmN232 mms113.5 mmS7.5 mmSW3 mmC14 kNC07.88 kNT min.-20 °CT max.100 °CRecommended tightening torque for set screw5.5 NmDesignation of housingT205- Designation of bearingUS205G2 Bearing numberUST205BrandSNRBore Diameter (mm)25d25 mmL451 mmL516 mmL210 mmL362 mms7.5 mmA32 mmA124 mmB127 mmD134 mmH89 mmH151 mmL97 mmL13…
Contact Us Now !

Product description

UST205 SNR A 32 mm Bearing units

A224 mm
B27 mm
A519.5 mm
GM6x1
H251 mm
N232 mm
s113.5 mm
S7.5 mm
SW3 mm
C14 kN
C07.88 kN
T min.-20 °C
T max.100 °C
Recommended tightening torque for set screw5.5 Nm
Designation of housingT205-
Designation of bearingUS205G2
Bearing numberUST205
BrandSNR
Bore Diameter (mm)25
d25 mm
L451 mm
L516 mm
L210 mm
L362 mm
s7.5 mm
A32 mm
A124 mm
B127 mm
D134 mm
H89 mm
H151 mm
L97 mm
L136.5 mm
N19 mm
N132 mm
Thread (G)M6x1
J112 mm
J276 mm
Weight0.8 Kg
Basic dynamic load rating (C)14 kN
