Home > Angular contact ball bearings > VEB 25 /NS 7CE1 SNFA 25x42x9mm r3 min. 0.15 mm Angular contact ball bearings
VEB 25 /NS 7CE1 SNFA 25x42x9mm  r3 min. 0.15 mm Angular contact ball bearings

VEB 25 /NS 7CE1 SNFA 25x42x9mm r3 min. 0.15 mm Angular contact ball bearings

Bearing numberVEB 25 /NS 7CE1Size (mm)25x42x9BrandSNFABore Diameter (mm)25Outer Diameter (mm)42Width (mm)9d25 mmD42 mmB9 mmC9 mma9 mmd130.7 mmr1 min.0.3 mmr2 min.0.3 mmr3 min.0.15 mmr4 min.0.15 mmD136.4 mmda min.27 mmDa max.40 mmdb min27 mmra max.0.3 mmrb max.0.15 mmdh8.1 mmDb max40.6 mmWeight0.036 KgBasic dynamic load rating (C)5.27 kNBasic static…
Contact Us Now !

Product description

VEB 25 /NS 7CE1 SNFA 25x42x9mm r3 min. 0.15 mm Angular contact ball bearings

Bearing numberVEB 25 /NS 7CE1
Size (mm)25x42x9
BrandSNFA
Bore Diameter (mm)25
Outer Diameter (mm)42
Width (mm)9
d25 mm
D42 mm
B9 mm
C9 mm
a9 mm
d130.7 mm
r1 min.0.3 mm
r2 min.0.3 mm
r3 min.0.15 mm
r4 min.0.15 mm
D136.4 mm
da min.27 mm
Da max.40 mm
db min27 mm
ra max.0.3 mm
rb max.0.15 mm
dh8.1 mm
Db max40.6 mm
Weight0.036 Kg
Basic dynamic load rating (C)5.27 kN
Basic static load rating (C0)2.85 kN
(Grease) Lubrication Speed58 000 r/min
(Oil) Lubrication Speed90 000 r/min

Cross-reference to other manufacturer’s part number

SL192316 Cylindrical roller bearings

Basic dynamic load rating (C):540 kN , Basic static load rating (C0):560 kN , Weight:6.32 Kg , D1:142.1 mm , S:3.5 mm
RB 30035 Thrust roller bearings

Basic dynamic load rating (C):183 kN , ds:322 mm , Weight:13.4 Kg , Dp:345 mm
240/500E Cylindrical roller bearings

Calculation factor (e):0.3 , Calculation factor (Y1):2.26 , Basic static load rating (C0):10500 kN , (Grease) Lubrication Speed:480 r/min , Calculation factor (Y0):2.21 , (Oil) Lubrication Speed:600 r/min
EXPE207 Bearing units

N:14 mm , Basic dynamic load rating (C):25.7 kN , Thread (G):R1/8" , Weight:1.7 Kg , N1:21 mm
TUP2 170.50 Plain bearings

f1:1.6 mm , θ:11 mm , L:50 mm , f2:0.8 mm
AR 7 30 47 Needle roller bearings

B1:7 mm , Basic static load rating (C0):77 kN , Basic dynamic load rating (C):26.5 kN , Eb:32.7 mm , Ea:42.3 mm , Weight:0.036 Kg
LMKM60UU Linear bearings

â„“:96.5 Tolerance h14 , Weight:4.5 Kg , Basic dynamic load rating (C):7.65 kN , PCD:112 mm , Tolerance perpendicularity (C):25
24864K30 Thrust roller bearings

D:400.000 mm , H:80.000 mm , Outer Diameter :400.000mm , d:320.000 mm , Width :80.000mm , Bore Diameter :320.000mm
B-55 Needle roller bearings

Width :7.92mm , Weight:0.0036 Kg , C:7.92 mm , Basic dynamic load rating (C):3.85 kN , Fw:7.938 mm , D:12.7 mm
WRP394644A Needle roller bearings

(Oil) Lubrication Speed:12000 r/min , Basic dynamic load rating (C):54.7 kN , (Grease) Lubrication Speed:7200 r/min , Basic static load rating (C0):107 kN
