VEX 30 /NS 7CE3 SNFA 30x55x13mm Da max. 50.4 mm Angular contact ball bearings

Bearing numberVEX 30 /NS 7CE3Size (mm)30x55x13BrandSNFABore Diameter (mm)30Outer Diameter (mm)55Width (mm)13d30 mmD55 mmB13 mmC13 mma16 mmd138.2 mmr1 min.1 mmr2 min.1 mmr3 min.0.6 mmr4 min.0.6 mmD145.8 mmda min.34.6 mmDa max.50.4 mmdb min34.6 mmra max.1 mmrb max.0.6 mmDb max50.8 mmWeight0.1 KgBasic dynamic load rating (C)8.84 kNBasic static load ra…

Product description

VEX 30 /NS 7CE3 SNFA 30x55x13mm Da max. 50.4 mm Angular contact ball bearings

Bearing number	VEX 30 /NS 7CE3
Size (mm)	30x55x13
Brand	SNFA
Bore Diameter (mm)	30
Outer Diameter (mm)	55
Width (mm)	13
d	30 mm
D	55 mm
B	13 mm
C	13 mm
a	16 mm
d1	38.2 mm
r1 min.	1 mm
r2 min.	1 mm
r3 min.	0.6 mm
r4 min.	0.6 mm
D1	45.8 mm
da min.	34.6 mm
Da max.	50.4 mm
db min	34.6 mm
ra max.	1 mm
rb max.	0.6 mm
Db max	50.8 mm
Weight	0.1 Kg
Basic dynamic load rating (C)	8.84 kN
Basic static load rating (C0)	5 kN
(Grease) Lubrication Speed	42 000 r/min
(Oil) Lubrication Speed	65 000 r/min

Cross-reference to other manufacturer’s part number

UKT211H Bearing units	J1:22 mm , Basic dynamic load rating (C):43.55 kN , Weight:4 Kg , J2:130 mm
24122BK30 Spherical roller bearings	Calculation factor (e):0.38 , (Oil) Lubrication Speed:2 400 r/min , Calculation factor (Y0):1.73 , Calculation factor (Y1):1.76
SIZJ12 Plain bearings	Body Dia. (d3):0.735 , Material – Body – Carbon steel-zinc plated, Ball – Hardened chrome steel-chrome plated:Hardened chrome steelchrome plated , Weight (g):132.00 , Body End Flats (W):0.750 , Body End Width (l5):0.250 , Body End Dia. (d4):0.875
ER211-35 Bearing units	Relubrication Hole Location (oh):7.5000 , Shaft Size (ds) – 2-3/16:23/16 , Weight (g):1.410.67 , Snap Ring Thickness (I):2.4000 , Snap Rinf Location (Sd):3.2000
AST090 20590 Plain bearings	ID Chamfer Angle (B deg.):45 , Material:Wrapped bronze with formed lubrication indents. , ID Chamfer Length (Ci):0.600 , OD Chamfer Length (Co):1.800
22205EMKW33 Spherical roller bearings	D:52.000 mm , d:25.000 mm , Outer Diameter :52.000mm , C:18.000 mm , B:18.000 mm , Width :18.000mm
UKFL315+H2315 Bearing units	N:35 mm , L1:206 mm , Bolt (G):M30 , A2:39 mm , L:195 mm , J:260 mm
SIL 22 Plain bearings	L:111 mm , S:22 mm , K:37 mm , J:30 mm , Bolt (G):M22x1.5
22211-2RSK Spherical roller bearings	Basic static load rating (C0):124.46 kN , K:3 mm , Basic dynamic load rating (C):122.5 kN , Weight:1 Kg
TAF 81512 Needle roller bearings	r min.:0.2 mm , Weight:0.0083 Kg , Basic dynamic load rating (C):4.61 kN , Da max.:12.4 mm , Basic static load rating (C0):4.05 kN
