VEX 90 7CE3 SNFA D1 121.66 mm 90x140x24mm  Angular contact ball bearings

VEX 90 7CE3 SNFA D1 121.66 mm 90x140x24mm Angular contact ball bearings

Bearing numberVEX 90 7CE3Size (mm)90x140x24BrandSNFABore Diameter (mm)90Outer Diameter (mm)140Width (mm)24d90 mmD140 mmB24 mmC24 mma39 mmd1108.3 mmr1 min.1.5 mmr2 min.1.5 mmr3 min.1 mmr4 min.1 mmD1121.66 mmda min.97 mmDa max.133 mmdb min97 mmra max.1.5 mmrb max.1 mmDb max134.4 mmWeight1.2 KgBasic dynamic load rating (C)33.8 kNBasic static load rati…
Contact Us Now !

Product description

VEX 90 7CE3 SNFA D1 121.66 mm 90x140x24mm Angular contact ball bearings

Bearing numberVEX 90 7CE3
Size (mm)90x140x24
BrandSNFA
Bore Diameter (mm)90
Outer Diameter (mm)140
Width (mm)24
d90 mm
D140 mm
B24 mm
C24 mm
a39 mm
d1108.3 mm
r1 min.1.5 mm
r2 min.1.5 mm
r3 min.1 mm
r4 min.1 mm
D1121.66 mm
da min.97 mm
Da max.133 mm
db min97 mm
ra max.1.5 mm
rb max.1 mm
Db max134.4 mm
Weight1.2 Kg
Basic dynamic load rating (C)33.8 kN
Basic static load rating (C0)30 kN
(Grease) Lubrication Speed12 000 r/min
(Oil) Lubrication Speed19 000 r/min

Cross-reference to other manufacturer’s part number

S51101 Thrust ball bearings

Basic dynamic load rating (C):9.035 kN , (Grease) Lubrication Speed:7000 r/min , H:9 mm , Basic static load rating (C0):10 kN
292/530 M Thrust roller bearings

Basic dynamic load rating (C):3100 kN , Weight:110 Kg , C:57 mm , T:109 mm , Basic static load rating (C0):16300 kN
NKX 12 Complex bearings

C2:6.5 mm , C1:9 mm , B:23 mm , D1:26.1 mm
SIJK14C Plain bearings

Material – Body – Carbon steel-zinc plated, Ball – Hardened chrome steel-chrome plated, Liner:PTFE composite material , Body End Width (l5):8.000 , Body End Flats (W):21.000 , Weight (g):200.00 , Body End Dia. (d4):25.000 , Body Dia. (d3):20.000
24168R Spherical roller bearings

(Oil) Lubrication Speed:580 r/min , Basic static load rating (C0):7620 kN , Calculation factor (Y0):1.62 , Calculation factor (e):0.41 , Calculation factor (Y1):1.66 , (Grease) Lubrication Speed:440 r/min
FY 2. TF/VA228 Bearing units

Basic static load rating C0:29 kN , Hexagonal key size for grub screw N:4.763 mm , Attachment bolts, recommended metric size G:16 mm , Grub (set) screw G2:3/8-24 UNF , Limiting temperature T max.:350 °C , Bearing:
YAR 211-200-2FW/VA228
LMEK8 Linear bearings

PCD:24 mm , L:25 mm , Tolerance perpendicularity (C):12 , Basic dynamic load rating (C):260 kN , Weight:0.044 Kg
1317S Self aligning ball bearings

Calculation factor (e):0.21 , Calculation factor (Y0):3.1 , Basic static load rating (C0):38 kN , Calculation factor (Y1):2.9 , (Oil) Lubrication Speed:4 000 r/min , (Grease) Lubrication Speed:3 400 r/min
24188 K30 CW33 Spherical roller bearings

Weight:460 Kg , (Grease) Lubrication Speed:170 r/min , Basic dynamic load rating (C):5980 kN , C:280 mm , Basic static load rating (C0):12200 kN
EXFCE209 Bearing units

Thread (G):M6x1 , Basic dynamic load rating (C):31.85 kN , Weight:2.1 Kg , A2:32.9 mm
