W619/2X SKF 2x6x2.5mm  r2 min. 0.15 mm Deep groove ball bearings

W619/2X SKF 2x6x2.5mm r2 min. 0.15 mm Deep groove ball bearings

Bearing numberW619/2XSize (mm)2x6x2.5BrandSKFBore Diameter (mm)2Outer Diameter (mm)6Width (mm)2.5d2 mmD6 mmB2.5 mmC2.5 mmd13 mmd2– mmr1 min.0.15 mmr2 min.0.15 mmD14.8 mmD2– mmda min.2.9 mmDa max.4.9 mmra max.0.15 mmWeight0.0003 KgBasic dynamic load rating (C)0.19 kNBasic static load rating (C0)0.051 kNFatigue load limit (Pu)0.002Reference speed…
Contact Us Now !

Product description

W619/2X SKF 2x6x2.5mm r2 min. 0.15 mm Deep groove ball bearings

Bearing numberW619/2X
Size (mm)2x6x2.5
BrandSKF
Bore Diameter (mm)2
Outer Diameter (mm)6
Width (mm)2.5
d2 mm
D6 mm
B2.5 mm
C2.5 mm
d13 mm
d2– mm
r1 min.0.15 mm
r2 min.0.15 mm
D14.8 mm
D2– mm
da min.2.9 mm
Da max.4.9 mm
ra max.0.15 mm
Weight0.0003 Kg
Basic dynamic load rating (C)0.19 kN
Basic static load rating (C0)0.051 kN
Fatigue load limit (Pu)0.002
Reference speed180000 r/min
Limiting speed110000 r/min
Calculation factor (f0)6

Cross-reference to other manufacturer’s part number

SCE78 Needle roller bearings

Max Speed (Grease) (X1000 RPM):25.000 , Weight (g):7.00 , Shaft (Fw):0.437 , Material – Drawn cup: Hardened carbon steel alloy, Rollers:52100 Chrome steel or equivalent
SL04-5016NR Cylindrical roller bearings

Basic dynamic load rating (C):205 kN , Basic static load rating (C0):350 kN , Weight:2.66 Kg , da:85 mm , Cf1:48 mm , Cf:48 mm
WTF450KVS5901Eg Tapered roller bearings

r1 min.:4 mm , Calculation factor (e):0.33 , r min.:5 mm , Basic dynamic load rating (C):5 550 kN , Basic static load rating (C0):15 000 kN , Calculation factor (Y2):3
T4EB240 Tapered roller bearings

Basic static load rating (C0):815 kN , (Grease) Lubrication Speed:900 r/min , Basic dynamic load rating (C):429 kN , Weight:8.45 Kg
100035/100072 Tapered roller bearings

Da:64 mm , Weight:0.38 Kg , da:45 mm , R:2 mm
T9020 Thrust roller bearings

r:9.7 mm , Basic static load rating (C0):11000000 kN , Basic dynamic load rating (Ca90):859000 , Weight:65.7 Kg
21319CE4 Spherical roller bearings

KBRG:2322 , SDM_:152.374 , r:3 , DI_:129.617 , SBRG:3 , calcUrl:/BearingGuide/html/calculation.jsp
160RF02 Cylindrical roller bearings

B:48 mm , r max:2.5 mm , C:48 mm , E:267 mm , D:290 mm
13687/13621 Tapered roller bearings

Basic static load rating (C0):62 kN , (Grease) Lubrication Speed:5600 r/min , (Oil) Lubrication Speed:7500 r/min , Calculation factor (e):0.4 , Calculation factor (Y0):0.82
202KG Deep groove ball bearings

D:35 mm , B:11 mm , Weight:0.041 Kg , C:11 mm , Basic dynamic load rating (C):8.65 kN
