W689-2RU KOYO Basic dynamic load rating (C) 1.35 kN 9x17x5mm  Deep groove ball bearings

W689-2RU KOYO Basic dynamic load rating (C) 1.35 kN 9x17x5mm Deep groove ball bearings

Bearing numberW689-2RUSize (mm)9x17x5BrandKOYOBore Diameter (mm)9Outer Diameter (mm)17Width (mm)5d9 mmD17 mmB5 mmC5 mmr min.0.2 mmr1 min.0.2 mmda min.10.6 mmDa max.15.4 mmra max.0.2 mmWeight0.0035 KgBasic dynamic load rating (C)1.35 kNBasic static load rating (C0)0.66 kN(Grease) Lubrication Speed35000 r/min Cross-reference to other manufacturer's p…
Contact Us Now !

Product description

W689-2RU KOYO Basic dynamic load rating (C) 1.35 kN 9x17x5mm Deep groove ball bearings

Bearing numberW689-2RU
Size (mm)9x17x5
BrandKOYO
Bore Diameter (mm)9
Outer Diameter (mm)17
Width (mm)5
d9 mm
D17 mm
B5 mm
C5 mm
r min.0.2 mm
r1 min.0.2 mm
da min.10.6 mm
Da max.15.4 mm
ra max.0.2 mm
Weight0.0035 Kg
Basic dynamic load rating (C)1.35 kN
Basic static load rating (C0)0.66 kN
(Grease) Lubrication Speed35000 r/min

Cross-reference to other manufacturer’s part number

UKP210 Bearing units

B:42 , (Refer.)Unit mass(kg):1/4-28UNF , S:3.0 , f0:14.4
AST090 23080 Plain bearings

ID Chamfer Angle (B deg.):45 , OD Chamfer Length (Co):1.800 , ID Chamfer Length (Ci):0.600 , Material:Wrapped bronze with formed lubrication indents.
UKP312+H2312 Bearing units

N1:38 mm , N:25 mm , H2:165 mm , J:250 mm , L:330 mm , Bolt (G):M20
NUP 211 ECJ Thrust ball bearings

Calculation factor kr:0.15 , Axial load factor Y:0.6 , Limiting value e:0.2 , Mass bearing:0.69 kg
YRTS 460 Thrust roller bearings

Static load rating radial (C0):570 kN , Static load rating axial (C0):1690 kN , Dynamic load rating radial (C):168 kN , Dynamic load rating axial (C):221 kN
RE 15025 Thrust roller bearings

Weight:3.16 Kg , ds:164 mm , Dp:182 mm , dh:194 mm , Basic dynamic load rating (C):76.8 kN , r min.:2 mm
VEB 20 /S/NS 7CE1 Angular contact ball bearings

Basic dynamic load rating (C):4.88 kN , (Grease) Lubrication Speed:68 000 r/min , Basic static load rating (C0):2.4 kN , Db max:35.6 mm , Weight:0.032 Kg
131095/131158XC Tapered roller bearings

da:110 mm , J:164.75 mm , Weight:2.29 Kg , R:2.5 mm
3305A Angular contact ball bearings

Reference speed:11000 r/min , Basic dynamic load rating (C):32 kN , Weight:0.35 Kg , Fatigue load limit (Pu):0.865 , ra max.:1 mm , Basic static load rating (C0):20.4 kN
KTSS12-PP-AS Linear bearings

Basic dynamic load rating (C):1.46 kN , Weight:0.21 Kg , H2:18 mm , H:35 mm , C2:56 mm
