YEL 207-106-2F SKF 72×34.925×51.1mm outside diameter: 72 mm Deep groove ball bearings

Home > Deep groove ball bearings > YEL 207-106-2F SKF 72×34.925×51.1mm outside diameter: 72 mm Deep groove ball bearings

YEL 207-106-2F SKF 72×34.925×51.1mm outside diameter: 72 mm Deep groove ball bearings

Bearing numberYEL 207-106-2FSize (mm)72x34.925x51.1BrandSKFBore Diameter (mm)72Outer Diameter (mm)34.925Width (mm)51.1d34.925 mmD72 mmB151.1 mmC19 mmd146.1 mmd251.1 mmB37.6 mmB46.75 mmr1,2 - min.1 mms132.3 mmBasic dynamic load rating - C25.5 kNBasic static load rating - C015.3 kNFatigue load limit - Pu0.655 kNLimiting speed with shaft tolerance h65…

Product description

YEL 207-106-2F SKF 72×34.925×51.1mm outside diameter: 72 mm Deep groove ball bearings

Bearing number	YEL 207-106-2F
Size (mm)	72×34.925×51.1
Brand	SKF
Bore Diameter (mm)	72
Outer Diameter (mm)	34.925
Width (mm)	51.1
d	34.925 mm
D	72 mm
B₁	51.1 mm
C	19 mm
d₁	46.1 mm
d₂	51.1 mm
B	37.6 mm
B₄	6.75 mm
r_1,2 – min.	1 mm
s₁	32.3 mm
Basic dynamic load rating – C	25.5 kN
Basic static load rating – C₀	15.3 kN
Fatigue load limit – P_u	0.655 kN
Limiting speed with shaft tolerance h6	5300 r/min
Calculation factor – f₀	14
Mass bearing	0.5 kg
Thread – G₂ – 3/8-24 UNF	3/824 UNF
Hexagonal key size for grub screw – H	4.762 mm
Category	Insert Bearings Spherical OD
BDI Inventory	0.0
Manufacturer Name	SKF
Minimum Buy Quantity	N/A
Weight / Kilogram	0.57
EAN	7316576617027
Product Group – BDI	M06110
Inner Race Profile	Wide Inner Ring
Outer Race Profile	Spherical
Relubricatable	Yes
Seal Type	M Seal
Mounting Method	Eccentric Collar
Rolling Element	Ball Bearing
Snap Ring	No
Long Description	1-3/8" Bore; Wide Inner Ring; Ball Bearing; 2.012" Length Thru Bore; 0.748" Outer Race Width; 2.835" Outside Diameter; Relubricatable; M Seal Seal; Eccentric Collar Mounting Method
Inch – Metric	Inch
Other Features	Single Row \| Standard Duty \| With Set Screw \| Has Flinger
Category – BDI	Insert Bearings
UNSPSC	31171536
Harmonized Tariff Code	8482.10.50.00
Noun	Bearing
Keyword String	Insert
Manufacturer URL	http://www.skf.com
Manufacturer Item Number	YEL 207-106-2F
Weight / LBS	1.26
Bore	1.375 Inch \| 34.925 Millimeter
Length Thru Bore	2.012 Inch \| 51.105 Millimeter
Outside Diameter	2.835 Inch \| 72.009 Millimeter
Outer Race Width	0.748 Inch \| 18.999 Millimeter
bore diameter:	1.3750 in
radial dynamic load capacity:	25.5 kN
outside diameter:	72 mm
radial static load capacity:	15.3 kN
outer ring width:	19 mm
bearing material:	Stainless Steel
inner ring width:	51.1 mm
finish/coating:	Zinc Plated
bore type:	Round
maximum rpm:	5300 RPM
locking device:	Eccentric Collar
seal type:	Contact with Flinger
operating temperature range:	-40 to +210 °F
series:	YEL2
B₁	51.1 mm
d₁ ≈	46.1 mm
d₂	51.1 mm
B₄	6.75 mm
r_1,2 min.	1 mm
s₁	32.3 mm
Basic dynamic load rating C	25.5 kN
Basic static load rating C₀	15.3 kN
Fatigue load limit P_u	0.655 kN
Limiting speed¹⁾	5300 r/min
Calculation factor f₀	14
Mass complete bearing	0.55 kg
Thread grub screw G₂	3/8-24 UNF
Hexagonal key size for grub screw N	4.763 mm
Recommended tightening torque for grub screw	16.5 N·m
Rubber seating ring	RIS 207 A

Cross-reference to other manufacturer’s part number

130063X/130120 Tapered roller bearings	da:84 mm , R:2.5 mm , F:5.56 mm , Weight:1.315 Kg , Da:107 mm
AST650 150170150 Plain bearings	ID Chamfer Angle (B deg.):15 , Material:Cast bronze with solid lubricant inserts. , OD Chamfer Length (Co):3.000 , Bearing Length Tolerance (B tol.) – -0.10 / -0.30:0.10 / 0.30 , ID Chamfer Length (Ci):1.200
UKPLE210H Bearing units	N:14 mm , Thread (G):M6x1 , Basic dynamic load rating (C):35.1 kN , N1:27 mm , Weight:2.9 Kg , L:214 mm
SL05 028 E Cylindrical roller bearings	C:70 mm , K:210 mm , Basic static load rating (C0):930 kN , Basic dynamic load rating (C):495 kN , Weight:8.2 Kg
24130EX1 Cylindrical roller bearings	Calculation factor (Y1):1.77 , Calculation factor (Y0):1.73 , (Oil) Lubrication Speed:2500 r/min , Basic static load rating (C0):1520 kN , (Grease) Lubrication Speed:1900 r/min , Calculation factor (e):0.38
2207-K-2RS+H307 Self aligning ball bearings	D1:52 mm , Weight:0.58 Kg , Basic static load rating (C0):5.9 kN , Basic dynamic load rating (C):14.5 kN
2216ETN9 Self aligning ball bearings	Calculation factor (Y1):2.9 , Calculation factor (Y0):2.8 , Calculation factor (e):0.22 , Calculation factor (kr):0.045 , Reference speed:8500 r/min , Limiting speed:6000 r/min
TSM 35 RB Spherical roller bearings	Thread (G):M36x2 , Weight:1.637 Kg , Angle:8.0 ° , Basic dynamic load rating (C):60 kN , B3:28 mm
VEX 8 7CE3 Angular contact ball bearings	Weight:0.012 Kg , (Grease) Lubrication Speed:98 000 r/min , Basic dynamic load rating (C):2.29 kN , (Oil) Lubrication Speed:150 000 r/min , Basic static load rating (C0):0.77 kN
205KLLG2 Deep groove ball bearings	P:16.13 mm , K:45.6 mm , Basic dynamic load rating (C):16 kN , C:15.01 mm , Weight:0.132 Kg
