100BTR10S NSK 100x150x22.5mm  Basic static load rating (C0) 114 kN Angular contact ball bearings

100BTR10S NSK 100x150x22.5mm Basic static load rating (C0) 114 kN Angular contact ball bearings

Bearing number100BTR10SSize (mm)100x150x22.5BrandNSKBore Diameter (mm)100Outer Diameter (mm)150Width (mm)22.5d100 mmD150 mmB22.5 mmC22.5 mmAngle (α)40 °a63.7 mmr min.1.5 mmr1 min.1 mm2B45 mmWeight1.399 KgBasic dynamic load rating (C)51.5 kNBasic static load rating (C0)114 kN(Grease) Lubrication Speed5 200 r/min(Oil) Lubrication Speed6 800…
Contact Us Now !

Product description

100BTR10S NSK 100x150x22.5mm Basic static load rating (C0) 114 kN Angular contact ball bearings

Bearing number100BTR10S
Size (mm)100x150x22.5
BrandNSK
Bore Diameter (mm)100
Outer Diameter (mm)150
Width (mm)22.5
d100 mm
D150 mm
B22.5 mm
C22.5 mm
Angle (α)40 °
a63.7 mm
r min.1.5 mm
r1 min.1 mm
2B45 mm
Weight1.399 Kg
Basic dynamic load rating (C)51.5 kN
Basic static load rating (C0)114 kN
(Grease) Lubrication Speed5 200 r/min
(Oil) Lubrication Speed6 800 r/min

Cross-reference to other manufacturer’s part number

AST11 2015 Plain bearings

OD Chamfer Length (Co):0.700 , Material:Bronze shell with PTFE / Fiber lining , ID Chamfer Length (Ci):0.500 , ID Chamfer Angle (B deg.):30
ZKLF3590-2RS-PE Thrust ball bearings

Basic static load rating (C0):89 kN , Bolt (G):M8 , Basic dynamic load rating (C):41 kN , Weight:1.13 Kg
3917 Thrust ball bearings

(Grease) Lubrication Speed:1100 r/min , Weight:3.157 Kg , D1:85.2 mm , Basic dynamic load rating (C):207 kN , Basic static load rating (C0):490 kN , r min.:1.5 mm
24144B Spherical roller bearings

Product Group – BDI:B04311 , Minimum Buy Quantity:N/A , EAN:4547359289503 , Weight / Kilogram:0
23240A2X Cylindrical roller bearings

(Oil) Lubrication Speed:1900 r/min , (Grease) Lubrication Speed:1500 r/min , Calculation factor (Y1):1.71 , Calculation factor (e):0.39 , Calculation factor (Y0):1.67
TUP1 06.08 Plain bearings

D:8 mm , f2:0.3 mm , f1:0.5 mm , L:8 mm
EXF319 Bearing units

Basic dynamic load rating (C):156 kN , A2:134.5 mm , N:35 mm , Thread (G):M10x1 , Weight:22.8 Kg
24172CAE4 Spherical roller bearings

Basic static load rating (C0):8000 kN , (Grease) Lubrication Speed:400 r/min , Calculation factor (Y2):2.5 , Calculation factor (e):0.4 , (Oil) Lubrication Speed:530 r/min , Calculation factor (Y0):1.7
14585/25 Tapered roller bearings

D:68.262 mm , Bore Diameter :34.925mm , d:34.925 mm , Width :20.638mm , Outer Diameter :68.262mm
AST650 152116 Plain bearings

ID Chamfer Length (Ci):1.200 , OD Chamfer Length (Co):2.000 , ID Chamfer Angle (B deg.):15 , Material:Cast bronze with solid lubricant inserts.
