1318K KOYO Rolling Element Ball Bearing 90x190x43mm  Self aligning ball bearings

1318K KOYO Rolling Element Ball Bearing 90x190x43mm Self aligning ball bearings

Bearing number1318KSize (mm)90x190x43BrandKOYOBore Diameter (mm)90Outer Diameter (mm)190Width (mm)43d90 mmD190 mmB43 mmC43 mmr min.3 mmda min.103 mmDa max.177 mmra max.2.5 mmWeight5.71 KgBasic dynamic load rating (C)116 kNBasic static load rating (C0)44.4 kN(Grease) Lubrication Speed3100 r/min(Oil) Lubrication Speed3800 r/minCalculation factor (e)0…
Contact Us Now !

Product description

1318K KOYO Rolling Element Ball Bearing 90x190x43mm Self aligning ball bearings

Bearing number1318K
Size (mm)90x190x43
BrandKOYO
Bore Diameter (mm)90
Outer Diameter (mm)190
Width (mm)43
d90 mm
D190 mm
B43 mm
C43 mm
r min.3 mm
da min.103 mm
Da max.177 mm
ra max.2.5 mm
Weight5.71 Kg
Basic dynamic load rating (C)116 kN
Basic static load rating (C0)44.4 kN
(Grease) Lubrication Speed3100 r/min
(Oil) Lubrication Speed3800 r/min
Calculation factor (e)0.22
Calculation factor (Y0)2.94
Calculation factor (Y1)2.81
CategorySelf Aligning Ball Bearings
BDI Inventory0.0
Manufacturer NameKOYO
Minimum Buy QuantityN/A
Weight / Kilogram6.167
EAN0605790002038
Product Group – BDIB00152
Mounting MethodTapered Adapter
EnclosureOpen
Rolling ElementBall Bearing
Adapter SleeveH-318X
Cage MaterialSteel
Precision ClassABEC 1 | ISO P0
Internal ClearanceC0-Medium
Number of Rows of BallsDouble Row
Other FeaturesAllowable Misalignment 3 Deg | 1:12 Taper
Long Description90MM Bore; Tapered Adapter Mount; 190MM Outside Diameter; 43MM Inner Race Width; 43MM Outer Race Width; Open; Steel Cage; Double Row of Balls; ABEC 1 | ISO P0; C0-Medium
Inch – MetricMetric
Category – BDISelf Aligning Ball Bearings
UNSPSC31171532
Harmonized Tariff Code8482.10.50.68
NounBearing
Keyword StringSelf Aligning
Manufacturer URLhttp://www.koyousa.com
Weight / LBS12.58838
Inner Race Width1.693 Inch | 43 Millimeter
Outer Race Width1.693 Inch | 43 Millimeter
Bore3.543 Inch | 90 Millimeter
Outside Diameter7.48 Inch | 190 Millimeter
