13685/13624 KOYO Calculation factor (Y0) 0.82  Tapered roller bearings

13685/13624 KOYO Calculation factor (Y0) 0.82 Tapered roller bearings

Bearing number13685/13624BrandKOYOBore Diameter (mm)38.1Width (mm)19.05d38.1 mmT21.996 mmB19.05 mmC18.029 mma16.1 mmr min.3.6 mmr1 min.1.6 mmDa61 mmdb43 mmda49.5 mmDb65 mmBasic dynamic load rating (C)49.2 kNBasic static load rating (C0)62 kNCalculation factor (e)0.4Calculation factor (Y0)0.82 Cross-reference to other manufacturer's part number NP62…
Contact Us Now !

Product description

13685/13624 KOYO Calculation factor (Y0) 0.82 Tapered roller bearings

Bearing number13685/13624
BrandKOYO
Bore Diameter (mm)38.1
Width (mm)19.05
d38.1 mm
T21.996 mm
B19.05 mm
C18.029 mm
a16.1 mm
r min.3.6 mm
r1 min.1.6 mm
Da61 mm
db43 mm
da49.5 mm
Db65 mm
Basic dynamic load rating (C)49.2 kN
Basic static load rating (C0)62 kN
Calculation factor (e)0.4
Calculation factor (Y0)0.82

Cross-reference to other manufacturer’s part number

NP626468/NP962387 Tapered roller bearings

D:80 mm , B:20 mm , d:50 mm , T:20 mm
239/530E Cylindrical roller bearings

Calculation factor (Y0):3.76 , (Oil) Lubrication Speed:670 r/min , (Grease) Lubrication Speed:540 r/min , Calculation factor (Y1):3.85 , Calculation factor (e):0.18 , Basic static load rating (C0):6800 kN
UKFE209H Bearing units

Weight:2.4 Kg , Basic dynamic load rating (C):31.85 kN , Thread (G):R1/8" , A2:50 mm
VEB 45 7CE1 Angular contact ball bearings

Basic dynamic load rating (C):10.1 kN , (Oil) Lubrication Speed:44 000 r/min , Basic static load rating (C0):6.95 kN , (Grease) Lubrication Speed:29 000 r/min
SC13V-B Linear bearings

W:44 mm , Weight:0.085 Kg , Basic dynamic load rating (C):0.5 kN , S2:4.3 mm
24152-B Spherical roller bearings

Calculation factor (e):0.42 , Reference speed:550 r/min , Calculation factor (Y1):1.61 , Limiting speed:1 100 r/min , Calculation factor (Y0):1.58 , Fatigue load limit (Pu):315
SIZP12S Plain bearings

C1:12.7 mm , Thread (G) – 1/2-20:1/220 , Weight:0.133 Kg , Basic dynamic load rating (C):15 kN , W:19.05 mm , Angle:9 °
23028EAW33 Thrust roller bearings

H:53.000 mm , d:140.000 mm , D:210.000 mm , Width :53.000mm
NX 30 Z Complex bearings

Dynamic load rating axial (C):12 kN , da:36.5 mm , Static load rating axial (C0):28 kN , Dynamic load rating radial (C):21 kN , Static load rating radial (C0):34 kN
X32312B/Y32312B Tapered roller bearings

r:2.5 mm , R:3 mm , T:48.5 mm , C:37 mm , B:46 mm
