Home > Angular contact ball bearings > 17BGR19H NSK 17x30x7mm (Oil) Lubrication Speed 120 000 r/min Angular contact ball bearings
17BGR19H NSK 17x30x7mm  (Oil) Lubrication Speed 120 000 r/min Angular contact ball bearings

17BGR19H NSK 17x30x7mm (Oil) Lubrication Speed 120 000 r/min Angular contact ball bearings

Bearing number17BGR19HSize (mm)17x30x7BrandNSKBore Diameter (mm)17Outer Diameter (mm)30Width (mm)7d17 mmD30 mmB7 mmC7 mmAngle (α)15 °a6.6 mmr min.0.3 mmr1 min.0.15 mmWeight0.015 KgBasic dynamic load rating (C)3.4 kNBasic static load rating (C0)1.5 kN(Grease) Lubrication Speed80 900 r/min(Oil) Lubrication Speed120 000 r/min Cross-reference…
Contact Us Now !

Product description

17BGR19H NSK 17x30x7mm (Oil) Lubrication Speed 120 000 r/min Angular contact ball bearings

Bearing number17BGR19H
Size (mm)17x30x7
BrandNSK
Bore Diameter (mm)17
Outer Diameter (mm)30
Width (mm)7
d17 mm
D30 mm
B7 mm
C7 mm
Angle (α)15 °
a6.6 mm
r min.0.3 mm
r1 min.0.15 mm
Weight0.015 Kg
Basic dynamic load rating (C)3.4 kN
Basic static load rating (C0)1.5 kN
(Grease) Lubrication Speed80 900 r/min
(Oil) Lubrication Speed120 000 r/min

Cross-reference to other manufacturer’s part number

3209-B-TVH Angular contact ball bearings

Basic dynamic load rating (C):48 kN , Fatigue load limit (Pu):1.8 , Weight:0.628 Kg , Basic static load rating (C0):37.5 kN , Reference speed:7 800 r/min , ra max.:1 mm
TAF 506235 Needle roller bearings

Basic dynamic load rating (C):58 kN , Da max.:60 mm , Weight:0.225 Kg , Basic static load rating (C0):125 kN
ER3.25.1800.400-1SPPN Thrust roller bearings

Hi:138 mm , De:2076.8 mm , Fe:1925 mm , He:117 mm , Fi:1685 mm , Ht:147 mm
NU 2206 ECJ Thrust ball bearings

Fatigue load limit Pu:6.1 kN , Basic static load rating C0:49 kN , Calculation factor kr:0.2 , Limiting value e:0.3 , Axial load factor Y:0.4 , Mass bearing:0.27 kg
2320 Self aligning ball bearings

(Grease) Lubrication Speed:2400 r/min , Calculation factor (e):0.34 , Calculation factor (Y0):1.93 , Basic static load rating (C0):73.4 kN , Calculation factor (Y1):1.84 , (Oil) Lubrication Speed:3400 r/min
AST650 150170150 Plain bearings

ID Chamfer Angle (B deg.):15 , OD Chamfer Length (Co):3.000 , ID Chamfer Length (Ci):1.200 , Material:Cast bronze with solid lubricant inserts.
3306A Angular contact ball bearings

Weight:0.52 Kg , Basic dynamic load rating (C):41.5 kN , Fatigue load limit (Pu):1.16 , Reference speed:9000 r/min , Basic static load rating (C0):27.5 kN
B-167 Needle roller bearings

Weight:0.019 Kg , Basic dynamic load rating (C):14 kN , C:11.13 mm , (Grease) Lubrication Speed:2800 r/min , Basic static load rating (C0):23.66 kN
T138W Thrust roller bearings

T:19.446 mm , d:35.179 mm , Width :19.446mm , R:0.8 mm , D:66.675 mm
AST20 18080 Plain bearings

ID Chamfer Length (Ci):0.800 , ID Chamfer Angle (B deg.):45 , Material:Carbon steel shell with POM plastic liner , Lube Hole Dia. (dl):9.500
