22206EK SKF D1 53 mm 30x62x20mm  Spherical roller bearings

22206EK SKF D1 53 mm 30x62x20mm Spherical roller bearings

Bearing number22206EKSize (mm)30x62x20BrandSKFBore Diameter (mm)30Outer Diameter (mm)62Width (mm)20d30 mmD62 mmB20 mmC20 mmb3.7 mmd237.6 mmr1 min.1 mmr2 min.1 mmD153 mmK2 mmda min.35.6 mmDa max.56.4 mmra max.1 mmWeight0.29 KgBasic dynamic load rating (C)64 kNBasic static load rating (C0)60 kNFatigue load limit (Pu)6.4Reference speed10000 r/minLimit…
Contact Us Now !

Product description

22206EK SKF D1 53 mm 30x62x20mm Spherical roller bearings

Bearing number22206EK
Size (mm)30x62x20
BrandSKF
Bore Diameter (mm)30
Outer Diameter (mm)62
Width (mm)20
d30 mm
D62 mm
B20 mm
C20 mm
b3.7 mm
d237.6 mm
r1 min.1 mm
r2 min.1 mm
D153 mm
K2 mm
da min.35.6 mm
Da max.56.4 mm
ra max.1 mm
Weight0.29 Kg
Basic dynamic load rating (C)64 kN
Basic static load rating (C0)60 kN
Fatigue load limit (Pu)6.4
Reference speed10000 r/min
Limiting speed14000 r/min
Calculation factor (e)0.31
Calculation factor (Y0)2.2
Calculation factor (Y1)2.2

Cross-reference to other manufacturer’s part number

234916 Thrust ball bearings

Weight:1.90 Kg , C:19 mm , H:38 mm , D:110 mm , Basic dynamic load rating (C):35 kN
24144RHA Spherical roller bearings

Y1:1.69 , Y0:1.65 , Y2:2.52 , (Refer.)Mass(kg):62.0
AST50 58IB48 Plain bearings

ID Chamfer Angle (B deg.):30 , Material:Carbon steel shell with PTFE / Fiber lining , ID Chamfer Length (Ci):0.031 , OD Chamfer Length (Co):0.072
NP518503/NP016286 Tapered roller bearings

d:40.483 mm , Width :28.575mm , B:28.575 mm , D:82.55 mm , Outer Diameter :82.55mm
WJ-323816 Needle roller bearings

(Grease) Lubrication Speed:5600 r/min , Basic static load rating (C0):98 kN , Basic dynamic load rating (C):56.5 kN , Weight:0.105 Kg
W208PPB7 Deep groove ball bearings

d:30.17 mm , Basic dynamic load rating (C):36.8 kN , C:18 mm , B:30.18 mm , D:80 mm , Weight:0.64 Kg
UKFLE215H Bearing units

Basic dynamic load rating (C):66 kN , Weight:4.9 Kg , Thread (G):R1/8" , L:160 mm , A2:73.5 mm , N:21 mm
AST50 104IB64 Plain bearings

ID Chamfer Length (Ci):0.031 , Material:Carbon steel shell with PTFE / Fiber lining , ID Chamfer Angle (B deg.):30 , OD Chamfer Length (Co):0.072
LBE 50 AJ Linear bearings

Groove Dia. (D1):71.500 , Adjustable Open Gap (h):2.000 , Groove Width (C2):2.600 , Weight (g):925.00 , Groove-to-groove length (C1):72.000 , Material:52100 chrome steel. or equivalent
18BTM2412 Needle roller bearings

(Grease) Lubrication Speed:12000 r/min , Weight:0.012 Kg , Basic dynamic load rating (C):7.9 kN , Basic static load rating (C0):10.9 kN
