2306 NACHI 30x72x27mm (Oil) Lubrication Speed 10000 r/min Self aligning ball bearings

What's New

Product Catalogs

2306 NACHI 30x72x27mm (Oil) Lubrication Speed 10000 r/min Self aligning ball bearings

Bearing number2306Size (mm)30x72x27BrandNACHIBore Diameter (mm)30Outer Diameter (mm)72Width (mm)27d30 mmD72 mmB27 mmC27 mmr1 min.1.1 mmda min.36.5 mmDa max.65.5 mmra max.1.0 mmWeight0.500 KgBasic dynamic load rating (C)31.4 kNBasic static load rating (C0)8.75 kN(Grease) Lubrication Speed8000 r/min(Oil) Lubrication Speed10000 r/minCalculation factor…

Product description

2306 NACHI 30x72x27mm (Oil) Lubrication Speed 10000 r/min Self aligning ball bearings

Bearing number	2306
Size (mm)	30x72x27
Brand	NACHI
Bore Diameter (mm)	30
Outer Diameter (mm)	72
Width (mm)	27
d	30 mm
D	72 mm
B	27 mm
C	27 mm
r1 min.	1.1 mm
da min.	36.5 mm
Da max.	65.5 mm
ra max.	1.0 mm
Weight	0.500 Kg
Basic dynamic load rating (C)	31.4 kN
Basic static load rating (C0)	8.75 kN
(Grease) Lubrication Speed	8000 r/min
(Oil) Lubrication Speed	10000 r/min
Calculation factor (e)	0.44
Calculation factor (Y0)	1.51
Calculation factor (Y1)	1.44

Cross-reference to other manufacturer’s part number

SCH108 Needle roller bearings	Material – Drawn cup: Hardened carbon steel alloy, Rollers:52100 Chrome steel or equivalent , Max Speed (Grease) (X1000 RPM):17.600 , Weight (g):13.00 , Shaft (Fw):0.625
TLAW3038 Z Needle roller bearings	Weight:0.069 Kg , Basic dynamic load rating (C):31.9 kN , Basic static load rating (C0):70.2 kN , C:38 mm , D:37 mm , Fw:30 mm
YSA210-2FK+HS2310 Deep groove ball bearings	Weight:0.94 Kg , Fatigue load limit (Pu):0.98 , Basic static load rating (C0):23.2 kN , Basic dynamic load rating (C):35.1 kN
16FSH35 Plain bearings	B1:20 mm , d1:30 mm , d:16 mm , C:12 mm , D:35 mm
1207S Self aligning ball bearings	(Oil) Lubrication Speed:10 000 r/min , (Grease) Lubrication Speed:8 500 r/min , Calculation factor (Y1):2.7 , Calculation factor (e):0.23 , Calculation factor (Y0):2.8
NJ 2218 ECJ Thrust ball bearings	Fatigue load limit Pu:39 kN , Limiting value e:0.3 , Calculation factor kr:0.2 , Angle ring: HJ 2218 EC , Axial load factor Y:0.4 , Mass bearing:3.2 kg
SL024856 Cylindrical roller bearings	Basic static load rating (C0):1860 kN , C:69 mm , Basic dynamic load rating (C):710 kN , Weight:15.6 Kg , S:4 mm
XLJ 12.1/2 Deep groove ball bearings	d:317.5 mm , Outer Diameter :419.1mm , C:50.8 mm , D:419.1 mm , B:50.8 mm , Width :50.8mm
YAR209-111-2F Deep groove ball bearings	Basic dynamic load rating (C):33.2 kN , Weight:0.75 Kg , s1:30.2 mm , Fatigue load limit (Pu):0.915 , Basic static load rating (C0):21.6 kN
YAR 206-2FW/VA201 Deep groove ball bearings	Hexagonal key size for grub screw N:3 mm , Basic static load rating C0:11.2 kN , Basic dynamic load rating C:19.5 kN , Limiting temperature T max.:250 °C , Recommended tightening torque for grub screw:4 N·m , Grub (set) screw G2:M6x0.75
