24130B NTN 150x250x100mm  Basic static load rating (C0) 1 520 kN Spherical roller bearings

24130B NTN 150x250x100mm Basic static load rating (C0) 1 520 kN Spherical roller bearings

Bearing number24130BSize (mm)150x250x100BrandNTNBore Diameter (mm)150Outer Diameter (mm)250Width (mm)100d150 mmD250 mmB100 mmC100 mmr min.2.1 mmda min.162 mmDa max.238 mmra max.2 mmWeight20.2 KgBasic dynamic load rating (C)885 kNBasic static load rating (C0)1 520 kN(Grease) Lubrication Speed1 300 r/min(Oil) Lubrication Speed1 700 r/minCalculation f…
Contact Us Now !

Product description

24130B NTN 150x250x100mm Basic static load rating (C0) 1 520 kN Spherical roller bearings

Bearing number24130B
Size (mm)150x250x100
BrandNTN
Bore Diameter (mm)150
Outer Diameter (mm)250
Width (mm)100
d150 mm
D250 mm
B100 mm
C100 mm
r min.2.1 mm
da min.162 mm
Da max.238 mm
ra max.2 mm
Weight20.2 Kg
Basic dynamic load rating (C)885 kN
Basic static load rating (C0)1 520 kN
(Grease) Lubrication Speed1 300 r/min
(Oil) Lubrication Speed1 700 r/min
Calculation factor (e)0.4
Calculation factor (Y0)1.65
Calculation factor (Y1)1.69

Cross-reference to other manufacturer’s part number

1607-2Z Deep groove ball bearings

C:7.937 mm , Weight:0.022 Kg , Basic dynamic load rating (C):1.78 kN , D:23.018 mm , B:7.937 mm , d:11.112 mm
AST090 10570 Plain bearings

Bearing Length Tolerance (B tol.) – +0 / -0.40:+0 / 0.40 , ID Chamfer Angle (B deg.):45 , OD Chamfer Length (Co):1.800 , ID Chamfer Length (Ci):0.600 , Material:Wrapped bronze with formed lubrication indents. , Bearing Length, Nominal (B):70.000
SA1013 Angular contact ball bearings

D:70 mm , B:43 mm , d:40 mm , C:43 mm , Width :43mm
LMK6UU Linear bearings

Tolerance perpendicularity (C):12 , L:19 mm , PCD:20 mm , K:22 mm , Weight:0.0265 Kg , Basic dynamic load rating (C):0.2 kN
LMKP10L Linear bearings

L:55 mm , PCD:29 mm , Weight:0.105 Kg , â„“:6 Tolerance h14 , Basic dynamic load rating (C):0.58 kN , Tolerance perpendicularity (C):15
3306-2RS Angular contact ball bearings

B:30.2 mm , D:72 mm , d:30 mm , C:30.2 mm
TNB44140S01 Needle roller bearings

Bore Diameter :34mm , Outer Diameter :59mm , D:59 mm , Width :20mm , d:34 mm
51130 Thrust ball bearings

(Refer.)Mass(kg):2.15 , R:- , da(min):174 , ra(max):1 , C:- , Da(max):166
W639/3-2RS1 Deep groove ball bearings

Reference speed:– r/min , Calculation factor (f0):6.1 , Fatigue load limit (Pu):0.004 , Limiting speed:43000 r/min
SK25ES Plain bearings

Weight:0.45 Kg , d5:4 r/min , Basic dynamic load rating (C):48 kN , Angle:7 °
