29260 SKF Cage Material Machined Brass 300x420x38mm  Thrust roller bearings

29260 SKF Cage Material Machined Brass 300x420x38mm Thrust roller bearings

Bearing number29260Size (mm)300x420x38BrandSKFBore Diameter (mm)300Outer Diameter (mm)420Width (mm)38d300 mmD420 mmC38 mmH73 mmd1405 mmr1 min.3 mmr2 min.3 mms162 mmB42.5 mmB169 mmD1353 mmda min.360 mmDa max.380 mmra max.2.5 mmWeight30.5 KgBasic dynamic load rating (C)1070 kNBasic static load rating (C0)4800 kNFatigue load limit (Pu)465Reference spe…
Contact Us Now !

Product description

29260 SKF Cage Material Machined Brass 300x420x38mm Thrust roller bearings

Bearing number29260
Size (mm)300x420x38
BrandSKF
Bore Diameter (mm)300
Outer Diameter (mm)420
Width (mm)38
d300 mm
D420 mm
C38 mm
H73 mm
d1405 mm
r1 min.3 mm
r2 min.3 mm
s162 mm
B42.5 mm
B169 mm
D1353 mm
da min.360 mm
Da max.380 mm
ra max.2.5 mm
Weight30.5 Kg
Basic dynamic load rating (C)1070 kN
Basic static load rating (C0)4800 kN
Fatigue load limit (Pu)465
Reference speed900 r/min
Limiting speed1400 r/min
CategoryThrust Roller Bearing
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram34.259
EAN7316577120045
Product Group – BDIB04311
Rolling ElementSpherical Roller Bearing
Self AligningYes
Component DescriptionRoller Assembly plus Raceways
Thrust BearingYes
Single or Double DirectionSingle Direction
BandedNo
Cage MaterialMachined Brass
Precision ClassABEC 1 | ISO P0
Other FeaturesSingle Row
Long Description300MM Bore 1; 353MM Bore 2; 420MM Outside Diameter; 73MM Height; Spherical Roller Bearing; Single Direction; Self Aligning; Not Banded; Machined Brass Cage; ABEC 1 | ISO P0; Roller Assembly plus Raceways
Inch – MetricMetric
Category – BDIThrust Roller Bearings
UNSPSC31171507
Harmonized Tariff Code8482.30.00.40
NounBearing
Keyword 3Spherical
Keyword StringThrust Roller Spherical
Manufacturer URLhttp://www.skf.com
Manufacturer Item Number29260
Weight / LBS67.241
Bore 111.811 Inch | 300 Millimeter
Outside Diameter16.535 Inch | 420 Millimeter
Height2.874 Inch | 73 Millimeter
Bore 213.898 Inch | 353 Millimeter
Overall Height with Aligning Washer0 Inch | 0 Millimeter
bore diameter:300 mm
dynamic load capacity:1070 kN
outside diameter:420 mm
maximum rpm:1400 RPM
overall width:73 mm
separable type:Non-Separable
operating temperature range:Maximum of +392 °F
fillet radius:2.5 mm
static load capacity:4800 kN
series:292
cage material:Brass
d1405 mm
D1353 mm
B169 mm
r1,2 min.3 mm
da min.360 mm
Da max.380 mm
ra max.2.5 mm
Basic dynamic load rating C1070 kN
Basic static load rating C04800 kN
Fatigue load limit Pu465 kN
Minimum axial load factor A2.2
Mass bearing30.5 kg
