3209-B-2RSR-TVH FAG D 85 mm 45x85x30.2mm  Angular contact ball bearings

3209-B-2RSR-TVH FAG D 85 mm 45x85x30.2mm Angular contact ball bearings

Bearing number3209-B-2RSR-TVHSize (mm)45x85x30.2BrandFAGBore Diameter (mm)45Outer Diameter (mm)85Width (mm)30.2d45 mmD85 mmB30.2 mmC30.2 mmAngle (α)25 °a43 mmd157.2 mmr min.1.1 mmD1– mmD275.5 mmda min.52 mmDa max.78 mmra max.1 mmWeight0.64 KgBasic dynamic load rating (C)48 kNBasic static load rating (C0)37.5 kNFatigue load limit (Pu)1.8…
Contact Us Now !

Product description

3209-B-2RSR-TVH FAG D 85 mm 45x85x30.2mm Angular contact ball bearings

Bearing number3209-B-2RSR-TVH
Size (mm)45x85x30.2
BrandFAG
Bore Diameter (mm)45
Outer Diameter (mm)85
Width (mm)30.2
d45 mm
D85 mm
B30.2 mm
C30.2 mm
Angle (α)25 °
a43 mm
d157.2 mm
r min.1.1 mm
D1– mm
D275.5 mm
da min.52 mm
Da max.78 mm
ra max.1 mm
Weight0.64 Kg
Basic dynamic load rating (C)48 kN
Basic static load rating (C0)37.5 kN
Fatigue load limit (Pu)1.8
Reference speed– r/min
