3209A SNR 45x85x30.200mm  Da max 78.5 mm Angular contact ball bearings

3209A SNR 45x85x30.200mm Da max 78.5 mm Angular contact ball bearings

d157.2 mmD172.6 mma43.2 mmContact angle α25 °rs min1.1 mmRadial clearance classCN Precision classP0 Mass0.58 kgDynamic load, C45.7 kNStatic load, C037.2 kNFatigue limit load, Cu2.27 kNf014.6 Nref6.500 rpmNlim7.500 rpmMin operating temperature, Tmin-20 °CMax operating temperature, Tmax120 °CCharacteristic cage frequency, FTF0.41 HzCharacteristic…
Contact Us Now !

Product description

3209A SNR 45x85x30.200mm Da max 78.5 mm Angular contact ball bearings

d157.2 mm
D172.6 mm
a43.2 mm
Contact angle α25 °
rs min1.1 mm
Radial clearance classCN
Precision classP0
Mass0.58 kg
Dynamic load, C45.7 kN
Static load, C037.2 kN
Fatigue limit load, Cu2.27 kN
f014.6
Nref6.500 rpm
Nlim7.500 rpm
Min operating temperature, Tmin-20 °C
Max operating temperature, Tmax120 °C
Characteristic cage frequency, FTF0.41 Hz
Characteristic rolling element frequency, BSF5.04 Hz
Characteristic outer ring frequency, BPF03.72 Hz
Characteristic inner ring frequency, BPFI5.28 Hz
da min51.5 mm
Da max78.5 mm
ra max1 mm
Bearing number3209A
Size (mm)45x85x30.200
BrandSNR
Bore Diameter (mm)45.000
Outer Diameter (mm)85.000
Width (mm)30.200
d45.000 mm
D85.000 mm
B30.200 mm
C30.200 mm
