Product description

AST090 13570 AST ID Chamfer Angle (B deg.) 45 Plain bearings

Bearing numberAST090 13570
BrandAST
Bore Diameter (mm)135
Outer Diameter (mm)140
Bearing Typestraight
Shaft Dia., Nominal (d)135.0000
Shaft Size (ds) – 135 -0.145 / -0.185135 0.145 / 0.185
Housing Bore Dia. (Dh) – 140 +0.040 / -0140 +0.040 / 0
Bearing Outside Diameter, Nominal(Do)140.000
Bearing Bore after Mounting (di) – 140 +0.100 / -0140 +0.100 / 0
Wall Thickness (S3)2.500
Bearing Length, Nominal (B)70.000
Bearing Length Tolerance (B tol.) – +0 / -0.40+0 / 0.40
OD Chamfer Length (Co)1.800
ID Chamfer Angle (B deg.)45
ID Chamfer Length (Ci)0.600
MaterialWrapped bronze with formed lubrication indents.

Cross-reference to other manufacturer’s part number

KBL40154-PP Linear bearings

Weight:1.17 Kg , W:2.15 mm , L1:121.2 mm , L:154 mm , Basic dynamic load rating (C):3.43 kN
3216-2RS Angular contact ball bearings

C:44.4 mm , D:140 mm , B1:44.4 mm , a:65.3 mm
22215EG15W33 Thrust roller bearings

D:130.000 mm , Width :31.000mm , d:75.000 mm , H:31.000 mm , Outer Diameter :130.000mm
T309W Thrust roller bearings

d:78.583 mm , Outer Diameter :102.395mm , R:0.8 mm , D:102.395 mm , T:15.875 mm , Width :15.875mm
SDM60OP Linear bearings

L:110 mm , Basic dynamic load rating (C):5170 kN , D1:86.5 mm , W:3.15 mm , Weight:1.85 Kg
S7209B Angular contact ball bearings

Basic static load rating (C0):25.4 kN , C:19 mm , (Grease) Lubrication Speed:6800 r/min , Basic dynamic load rating (C):37.2 kN , Weight:0.4 Kg
22317UAVS2 Thrust roller bearings

static load capacity::370000 N , manufacturer product page::Click here , series::223 , maximum rpm::2300 rpm
NU 414 Thrust ball bearings

Limiting value e:0.2 , Axial load factor Y:0.6 , Mass bearing:5.24 kg , Calculation factor kr:0.15 , Angle ring:
HJ 414
VLI 20 0844 N Thrust ball bearings

Dynamic load rating axial (C):222 kN , Dynamic load rating radial (C):145 kN , Weight:61.5 Kg , Static load rating radial (C0):224 kN
8MKM1210 Needle roller bearings

D:12 mm , Basic static load rating (C0):3.85 kN , C:10 mm , b:8.4 mm , Weight:0.0041 Kg , Basic dynamic load rating (C):3.25 kN
