AST20  08IB14 AST Average Clearance (Cd) 0.0040  Plain bearings

AST20 08IB14 AST Average Clearance (Cd) 0.0040 Plain bearings

Bearing numberAST20 08IB14BrandASTBore Diameter (mm)12.7Outer Diameter (mm)15.0876Bearing TypestraightShaft Dia., Nominal (d)0.5000Shaft Size (ds)0.4897 / 0.4887Housing Bore Dia. (Dh)0.5944 / 0.5937Bearing Outside Diameter, Nominal(Do)0.594Bearing Bore after Mounting (di)0.4944 / 0.4917Average Clearance (Cd)0.0040Wall Thickness (S3)0.051Bearing Len…
Contact Us Now !

Product description

AST20 08IB14 AST Average Clearance (Cd) 0.0040 Plain bearings

Bearing numberAST20 08IB14
BrandAST
Bore Diameter (mm)12.7
Outer Diameter (mm)15.0876
Bearing Typestraight
Shaft Dia., Nominal (d)0.5000
Shaft Size (ds)0.4897 / 0.4887
Housing Bore Dia. (Dh)0.5944 / 0.5937
Bearing Outside Diameter, Nominal(Do)0.594
Bearing Bore after Mounting (di)0.4944 / 0.4917
Average Clearance (Cd)0.0040
Wall Thickness (S3)0.051
Bearing Length, Nominal (B)0.875
Bearing Length Tolerance (B tol.) – +.010 / -0.010+.010 / 0.010
OD Chamfer Length (Co)0.024
ID Chamfer Angle (B deg.)30
ID Chamfer Length (Ci)0.012
MaterialCarbon steel shell with POM plastic liner

Cross-reference to other manufacturer’s part number

150RF92 Cylindrical roller bearings

r max:2.5 mm , C:88.9 mm , F:170 mm , D:270 mm , E:250 mm , B:88.9 mm
135 Self aligning ball bearings

(Grease) Lubrication Speed:30000 r/min , Calculation factor (e):0.34 , Calculation factor (Y1):1.86 , Basic static load rating (C0):0.48 kN , Calculation factor (Y0):1.94 , (Oil) Lubrication Speed:37000 r/min
T95 Thrust roller bearings

R:0.8 mm , d:24.13 mm , Outer Diameter :50.8mm , Width :15.875mm , D:50.8 mm , T:15.875 mm
LMEKP12 Linear bearings

â„“:6 Tolerance h14 , Weight:0.086 Kg , Basic dynamic load rating (C):0.41 kN , Tolerance perpendicularity (C):12 , PCD:32 mm
36RFN4125A Needle roller bearings

Weight:0.027 Kg , Basic dynamic load rating (C):29.9 kN , B:25 mm , Ew:41 mm , Basic static load rating (C0):60.6 kN
ER209-27 Bearing units

Weight (g):898.11 , Snap Ring Thickness (I):1.7000 , Snap Rinf Location (Sd):3.2000 , Relubrication Hole Location (oh):6.0000 , Shaft Size (ds) – 1-11/16:111/16 , Snap Ring Dia. (G):91.4000
WB000029 Angular contact ball bearings

C:37 mm , B:37 mm , Weight:0.62 Kg , Width :37mm , D:72 mm , d:39 mm
VEX 17 /NS 7CE3 Angular contact ball bearings

(Grease) Lubrication Speed:68 000 r/min , Basic static load rating (C0):2.45 kN , (Oil) Lubrication Speed:103 000 r/min , Weight:0.03 Kg , Basic dynamic load rating (C):5.59 kN
234448 MSP Thrust ball bearings

Basic dynamic load rating (C):325 kN , (Grease) Lubrication Speed:1500 r/min , D1:322 mm , Weight:43.8 Kg , Basic static load rating (C0):965 kN
VLA 20 0744 N Thrust ball bearings

Dynamic load rating radial (C):138 kN , Dynamic load rating axial (C):211 kN , Weight:54.5 Kg , Static load rating radial (C0):198 kN
