AST50 112IB48 AST  Material Carbon steel shell with PTFE / Fiber lining Plain bearings

AST50 112IB48 AST Material Carbon steel shell with PTFE / Fiber lining Plain bearings

Bearing numberAST50 112IB48BrandASTBore Diameter (mm)177.8Bearing TypestraightShaft Dia., Nominal (d)7.0000Shaft Size (ds) - 6.99546.9929Housing Bore Dia. (Dh) - 7.1837.1812Bearing Bore after Mounting (di) - 7.00266.9956Average Clearance (Cd)0.0048Wall Thickness (S3)0.095Bearing Length, Nominal (B)3.000Bearing Length Tolerance (B tol.) - +.010 / -0…
Contact Us Now !

Product description

AST50 112IB48 AST Material Carbon steel shell with PTFE / Fiber lining Plain bearings

Bearing numberAST50 112IB48
BrandAST
Bore Diameter (mm)177.8
Bearing Typestraight
Shaft Dia., Nominal (d)7.0000
Shaft Size (ds) – 6.99546.9929
Housing Bore Dia. (Dh) – 7.1837.1812
Bearing Bore after Mounting (di) – 7.00266.9956
Average Clearance (Cd)0.0048
Wall Thickness (S3)0.095
Bearing Length, Nominal (B)3.000
Bearing Length Tolerance (B tol.) – +.010 / -0.010+.010 / 0.010
OD Chamfer Length (Co)0.072
ID Chamfer Angle (B deg.)30
ID Chamfer Length (Ci)0.031
MaterialCarbon steel shell with PTFE / Fiber lining

Cross-reference to other manufacturer’s part number

SF6203 Angular contact ball bearings

C:60.000 mm , B:60.000 mm , D:429.500 mm , d:310.000 mm
SL01-4924 Cylindrical roller bearings

Weight / LBS:6.387 , Bore:4.724 Inch | 120 Millimeter , Width:1.772 Inch | 45 Millimeter , Outside Diameter:6.496 Inch | 165 Millimeter , Manufacturer Item Number:SL01-4924 , Manufacturer URL:http://www.ntnamerica.com
240/670EK30 Cylindrical roller bearings

(Oil) Lubrication Speed:430 r/min , Calculation factor (Y0):2.16 , (Grease) Lubrication Speed:340 r/min , Calculation factor (Y1):2.21 , Calculation factor (e):0.31
140082X/140140G Tapered roller bearings

L:8 mm , R:3 mm , Weight:4.145 Kg , da:100 mm , db:135 mm
AST11 2012 Plain bearings

OD Chamfer Length (Co):0.700 , ID Chamfer Length (Ci):0.500 , ID Chamfer Angle (B deg.):30 , Bearing Length, Nominal (B):12.000 , Material:Bronze shell with PTFE / Fiber lining , Bearing Length Tolerance (B tol.) – +0 / -0.30:+0 / 0.30
EXFS313 Bearing units

Weight:9.2 Kg , Basic dynamic load rating (C):93.86 kN , L:208 mm , A2:68.2 mm , N:23 mm , Thread (G):M6x1
TUP1 20.10 Plain bearings

f2:0.4 mm , D:23 mm , d:20 mm , f1:0.8 mm , L:10 mm
AST40 SP1.0 Plain bearings

Strip Width, Nominal (Ws):150 , Strip Length, Nominal (Ls):500 , Material:Steel shell with PTFE / Polymer Fiber lining , Strip Width Tolerance (Ws tol.) – +1 / -1:+1 / 1 , Strip Length Tolerance (Ls tol.) – +1 / -1:+1 / 1
K81206TN Thrust roller bearings

D:52 mm , Weight:0.033 Kg , Basic dynamic load rating (C):63.5 kN , Dw:7.5 mm , Basic static load rating (C0):139 kN , d:30 mm
2314 Self aligning ball bearings

Weight (g):3.900.00 , Precision:A1 , Material:52100 Chrome steel (or equivalent) , Min. Housing Shoulder Dia., Outer (Lo):139.0 , Standard Clearance:C0
