CNC STAINLESS STEEL M8 395 MM LEAD SCREW/DELRIN NUT/BEARING ASSEMBLY – 1 set

CNC STAINLESS STEEL M8 395 MM LEAD SCREW/DELRIN NUT/BEARING ASSEMBLY – 1 set

Automation, Motors & Drives>Sensors>Other Sensors CNC STAINLESS STEEL M8 395 MM LEAD SCREW/DELRIN NUT/BEARING ASSEMBLY - 1 set BUTT1 BUTT2 BUTT3 Stainless steel 395 mm leadscrew-delrin nut-bearing assembly Specifications LEAD SCREW Length Diameter Pitch Material Finish DELRIN NUT Thread Material Dimensions Mounting Hole pitch BEARING Bore…
Contact Us Now !

Product description

CNC STAINLESS STEEL M8 395 MM LEAD SCREW/DELRIN NUT/BEARING ASSEMBLY – 1 set

Automation, Motors & Drives>Sensors>Other Sensors

CNC STAINLESS STEEL M8 395 MM LEAD SCREW/DELRIN NUT/BEARING ASSEMBLY – 1 set

Stainless steel 395 mm leadscrew-delrin nut-bearing assembly

Specifications

LEAD SCREW

Length
Diameter
Pitch
Material
Finish

DELRIN NUT

Thread
Material
Dimensions
Mounting
Hole pitch

BEARING

Bore diameter
Dimensions
Mounting
Hole pitch
Material
Color

395 mm
8 mm
1.25 mm
Stainless steel
Polished

M8 1.25 mm pitch
Delrin (acetal )
35 mm x 30 mm x 13 mm
2 hole fixing
20 mm

8 mm
38 mm x 38 mm x 12 mm
4 hole fixing
25mm x 25mm
Composite
White

Description
Each set consists of a 395 mm M8 lead
screw, anti-backlash delrin nut, and 2 rectangular flange bearings with 2 M8
stainless steel fixing nuts.

This set has been designed specifically for the CNC hobbyist in
mind, to provide a low cost solution for providing linear motion when
coupled with a stepper motor. This lead screw diameter is 8 mm with a
standard M8 1.25 mm pitch.

This pitch is ideal for small hobby CNC machines, where large speeds
are not required, as the fine pitch provides good precision whilst
requiring minimal force from a stepper motor, and thus is suitable for
direct drive with small stepper motors. Due to the high resolution
(0.00625 mm per full step on a standard 1.8 degree motor) vibration is
negligible and a simple drive can be used without micro-stepping, thus
further reducing cost.

The lead screw is supplied polished and fitted with our delrin
anti-backlash nut which has a standard 1.25 mm pitch. Two flange bearings
are supplied for each lead screw which can be easily mounted onto a
flat surface of the machine member.

The delrin nut is manufactured from grade A delrin (Acetal homoplymer
B) supplied from a reputable European manufacturer. This material is
extremely hard wearing, and normally does not require lubrication. Due
to its mechanical properties there is minimum wear and backlash. The
form of the nut is as a rectangular block with 2 mounting holes, and as
such can be directly attached to the moving base, without need for
brackets or additional items.

The compact flange bearings provide convenient easy to mount bearings
in a housing with a matching 8 mm bore for the lead screw and has an 8
mm bore diameter.The compact size of this bearing is ideal for small
CNC machines where space is limited. The housing is made of a sturdy
high density composite material and is fitted with an 8 mm bore
bearing. Each flange bearings is supplied with 2 stainless steel
nuts for fixing to the stainless steel lead screw.

This item is shipped by registered international air
mail
