Product description

FYTB 1.1/2 TF SKF radial static load capacity: 4280 lbf 38.1×38.5x14mm Bearing units

Bearing numberFYTB 1.1/2 TF
Size (mm)38.1×38.5×14
BrandSKF
Bore Diameter (mm)38.1
Outer Diameter (mm)38.5
Width (mm)14
d38.1 mm
A38.5 mm
A114 mm
A3 – H143.2 mm
A523.5 mm
B49.2 mm
B48 mm
Da – H1188.9 mm
Db198 mm
Db2102 mm
J143.5 mm
H171.5 mm
L102 mm
H14 mm
s130.2 mm
T54.2 mm
J6115.5 mm
J716 mm
N42 mm
DN6.5 mm
SWN7 mm
GN – 1/4-28 SAE-LT1/428 SAELT
RG – 1/4-28 UNF1/428 UNF
R124.5 mm
Rα45 °
Basic dynamic load rating – C30.7 kN
Basic static load rating – C019 kN
Fatigue load limit – Pu0.8 kN
Limiting speed4800 r/min
Mass bearing unit1.55 kg
Thread – G2 – 5/16-24 UNF5/1624 UNF
Hexagonal key size for grub screw – H3.969 mm
CategoryFlange Block Bearings
BDI Inventory0.0
Manufacturer NameSKF
Minimum Buy QuantityN/A
Weight / Kilogram1.7
EAN7316570299977
Product Group – BDIM06110
Number of Mounting Holes2
Mounting MethodSet Screw
Housing Style2 Bolt Flange Block
Rolling ElementBall Bearing
Housing MaterialCast Iron
Expansion / Non-expansionNon-expansion
Mounting Bolts1/2 Inch
RelubricatableYes
Insert Part NumberYAR 208-108-2F
SealsM Seal
Housing Configuration1 Piece Solid
Pilot ConfigurationNo Pilot
Inch – MetricInch
Long Description2 Bolt Flange Block; 1-1/2" Bore; 5.7" Bolt Circle; 5.65" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 1-15/16" Length Thru Bore; Relubricatable; M Seal Seals
Other FeaturesSingle Row | Standard Duty | Wide Inner Race | Open End | Has Flinger | Y Bearing
Category – BDIFlange Block
UNSPSC31171501
Harmonized Tariff Code8483.20.40.40
NounBearing
Keyword StringFlanged
Manufacturer URLhttp://www.skf.com
Manufacturer Item NumberFYTB 1.1/2 TF
Weight / LBS3.75
Bore1.5 Inch | 38.1 Millimeter
Length Thru Bore1.937 Inch | 49.2 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
Bolt Spacing5.65 Inch | 143.5 Millimeter
Cartridge Pilot Depth0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round5.7 Inch | 144 Millimeter
bore diameter:1.5000 in
radial static load capacity:4280 lbf
bolt center-to-center length:143.5 mm
length through bore:54.2 mm
overall length/diameter:102 mm
finish/coating:Uncoated
bore type:Round
maximum rpm:4800 RPM
mounting type:Two-Bolt Flange
lubrication type:Lubrication Fitting
housing material:Cast Iron
series:FYTB
locking device:Set Screw
replacement bearing:YAR 208-108-2F
expansion type:Non-Expansion Bearing (Fixed)
manufacturer upc number:7316570299977
radial dynamic load capacity:6910 lbf
Housing materialCast iron
Da88.9 mm
Db198 mm
Db2102 mm
A114 mm
A33.2 mm
A526 mm
B48 mm
N14 mm
s130.2 mm
RG1/4-28 UNF
R124.5 mm
Rα45 °
DN6.5 mm
SWN7 mm
GN1/4-28 SAE-LT
J6115.5 mm
J716 mm
N42 mm
Basic dynamic load rating C30.7 kN
Basic static load rating C019 kN
Fatigue load limit Pu0.8 kN
Thread grub screw G25/16-24 UNF
Hexagonal key size for grub screw N3.969 mm
Recommended tightening torque for grub screw6.5 N·m
Recommended diameter for attachment bolts, mm G12 mm
Recommended diameter for attachment bolts, inch G0.5 in
