McGill – Sleeve Bearing Assembly – P/N: 309010 (NOS)

McGill – Sleeve Bearing Assembly – P/N: 309010 (NOS)

Heavy Equipment Parts & Accs>Manufacturing Equipment Parts>Bearings>See more McGill - Sleeve Bearing Assembly - P N 309010 ... McGill - Sleeve Bearing Assembly - P/N: 309010 (NOS) Genuine U.S. Military Issue Surplus   McGill - Sleeve Bearing Assembly - P/N: 309010 (NOS)  (NOS) = New Old Stock P/N: 309010 NSN: 3120-00-529-9641 On the sl…
Contact Us Now !

Product description

McGill – Sleeve Bearing Assembly – P/N: 309010 (NOS)

Heavy Equipment Parts & Accs>Manufacturing Equipment Parts>Bearings>See more McGill – Sleeve Bearing Assembly – P N 309010 …

McGill – Sleeve Bearing Assembly – P/N: 309010 (NOS)

Genuine U.S. Military Issue Surplus



McGill – Sleeve Bearing Assembly – P/N: 309010 (NOS)

(NOS) = New Old Stock

P/N: 309010

NSN: 3120-00-529-9641

On the sleeve bearing assembly it has….
MCGILL
SK – 12672

This Sleeve Bearing Assembly cross-references to Outboard Marine Corporation.
OMC P/N: 302585
OMC P/N:  30910
OMC P/N: 309010

The Sleeve Bearing Assembly consists of….

two half bearings and a spring to hold it in place.

We did not separate the Sleeve Bearing Assembly in the pictures.

3/4″ x 1 1/2″ Outer Diameter
1 1/4″ Inner Diameter
(See Pictures)

There are two holes on the side of the sleeve bearing, they are….
3/16″ Inner Diameter hole that goes completely thru the one side.
3/32″ Inner Diameter hole that does not go all the way thru the side.
(See Pictures)

There is a 1/16″ groove around the sleeve bearing for the spring to hold the sleeve bearing assembly together.
(See Pictures)

Characteristics

Hole Diameter:   0.2130 inches nominal first

Overall Length:  0.8200 inches minimum and 0.8240 inches maximum

Body Outside Diameter:   1.5000 inches minimum and 1.5005 inches maximum

Body Inside Diameter: 1.2515 inches minimum and 1.2520 inches maximum

Lubricant Accommodation Style: Grooved circular

Corner Shape: Round all corners

Features Provided: Casehardened

Hardness Rating: 60.0 rockwell C minimum overall and 64.0 rockwell C maximum overall

Antirotation/Lubrication Type and Quantity: 1 hole

Surface Groove Location and Quantity: 1 internal

Material: Steel comp 5160 overall

Style Designator: Segmented

Similar to the one in the pictures.

  Unused!

There is a little bit of discoloration.

*****************************************************************************************************************
