ABR090-100-S2-P2 Right angle precision planetary gear reducer

✖

Home>Products>Reducers>ABR090-100-S2-P2 Right angle precision planetary gear reducer image

ABR090-100-S2-P2 Right angle precision planetary gear reducer image

Reducers Specification details

Ea:113,28 mm
Eb:98,04 mm
Weight:0,05 Kg
Basic dynamic load rating (C):56,05 kN
Basic static load rating (C0):344,3 kN
Category:Thrust Roller Bearings
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.05
Product Group:B04144
Rolling Element:Needle Roller Bearing
Self Aligning:No
Component Description:Roller Assembly Only
Thrust Bearing:Yes
Single or Double Direction:Single Direction
Banded:No
Cage Material:Steel
Precision Class:ABEC 1 | ISO P0
Other Features:Single Row | Two Piece Cage
Long Description:3-3/4" Bore 1; 3-3/4" Bore 2; 4-5/8" Outside Diameter; 1/8" Height; Needle Roller Bearing; Single Direction; Not Self Aligning; Not Banded; Steel Cage; ABEC 1 | ISO P0; Roller Asse
Inch - Metric:Inch
UNSPSC:31171500
Harmonized Tariff Code:8482.99.25.40
Noun:Roller Assembly
Keyword String:Thrust Needle
Manufacturer Item Number:NTA-6074
Weight / LBS:0.11
Height:0.125 Inch | 3.175 Millimeter
Bore 1:3.75 Inch | 95.25 Millimeter
Bore 2:3.75 Inch | 95.25 Millimeter
Outside Diameter:4.625 Inch | 117.475 Millimeter
Overall Height with Aligning Washer:0 Inch | 0 Millimeter
Bearing No.:NTA-6074
Dc1:95.25
Dc:117.48
Dw:3.175
Ca:56.05
C0a:344.3
Cu:35.5
Limiting speeds(min-1):3500
(Refer.)Mass(kg):0.050
Washer designation:TRA-6074
d1:117.48
h(max):0.81
h(min):0.76
S(max):95.25
S(min):95.17
H:118.26
(Refer.)Washer mass(kg):0.023
