4WE6H73B6X/EG24N9K4/A12 Rexroth Type 4WE6H Directional Valves Details

C:50 mm
r min.:3 mm
da min.:123 mm
da max:149 mm
Da max.:227 mm
ra max.:2,5 mm
Weight:9,54 Kg
Basic dynamic load rating (C):205 kN
Basic static load rating (C0):179 kN
(Grease) Lubrication Speed:2 900 r/min
(Oil) Lubrication Speed:3 400 r/min
rs min:3 mm
Radial clearance class:CN
Mass:9.54 kg
Dynamic load, C:205 kN
Static load, C0:179 kN
Fatigue limit load, Cu:6.1 kN
f0:13.1
Nlim (oil):3,400 rpm
Nlim (grease):2,900 rpm
Min operating temperature, Tmin:-20 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.38 Hz
Characteristic rolling element frequency, BSF:4.04 Hz
Characteristic outer ring frequency, BPF0:3.06 Hz
Characteristic inner ring frequency, BPFI:4.94 Hz
da min:123 mm
Da max:227 mm
ra max:2.5 mm
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:9.57
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:110MM Bore; 240MM Outside Diameter; 50MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6322
Weight / LBS:21.083
Outside Diameter:9.449 Inch | 240 Millimeter
Bore:4.331 Inch | 110 Millimeter
Outer Race Width:1.969 Inch | 50 Millimeter
bore diameter::110 mm
precision rating::Class 0
outside diameter::240 mm
finish/coating::Uncoated
overall width::50 mm
bearing material::High Carbon Chrome Steel
bore type::Round
cage material::Steel
closure type::Open
inner ring width::50 mm
row type & fill slot::Single Row Non-Fill Slot
outer ring width::50 mm
snap ring included::Without Snap Ring
maximum rpm (grease)::2900 rpm
internal clearance::CN
maximum rpm (oil)::3400 rpm
operating temperature range::-40 to 120 ºC
fillet radius::3 mm
dynamic load capacity::205000 N
manufacturer product page::Click here
static load capacity::179000 N
