SKF 109KSZZG - Leader Industrial Manufacture

✖

SKF 109KSZZG image

SKF 109KSZZG Characteristics

Number of Bearings:2 (1 Pair)
Contact Angle:15 Degree
Preload:Light
Raceway Style:1 Rib Outer Ring
Cage Material:Phenolic
Rolling Element:Ball Bearing
Mounting Arrangement:Duplex-Universal
Flush Ground:Yes
Inch - Metric:Metric
Other Features:Single Row | Angular Contact | Bore and OD are Exclusive All Others are ISO 4
Long Description:45MM Bore; 68MM Outside Diameter; 24MM Width; Open Enclosure; ABEC 7 | ISO P4 Precision; Steel Ball Material; 2 (1 Pair) Bearings; 15 Degree Contact Angle; Phenolic Cage Material; 1 Rib Outer Ring Rac
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact Ball
Manufacturer Item Number:7909CTRDULP4Y
Weight / LBS:0.551
D:2.677 Inch | 68 Millimeter
d:1.772 Inch | 45 Millimeter
B:0.945 Inch | 24 Millimeter
bore diameter::45 mm
radial dynamic load capacity::1630 kgf
outside diameter::68 mm
radial static load capacity::1360 kgf
overall width::12 mm
maximum rpm::20000 RPM
contact angle::15 °
cage material::Synthetic Resin
internal clearance::C0
finish/coating::Uncoated
ball screw application::Not for Ball Screws
outer ring width::12 mm
closure type::Open
fillet radius::0.6 mm
precision rating::ABEC 7 (ISO Class 4)
series::79
