Home>Products>Roller Bearings>TIMKEN 593A-90178 image

TIMKEN 593A-90178 image

Back to product page

Customers who bought this item also bought Roller Bearings

d1:60.6 mm
D2:68.6 mm
r1,2 - min.:0.3 mm
da - min.:57 mm
da - max.:60.5 mm
Da - max.:70 mm
ra - max.:0.3 mm
Basic dynamic load rating - C:9 kN
Basic static load rating - C0:8.8 kN
Fatigue load limit - Pu:0.375 kN
Reference speed:19000 r/min
Limiting speed:9500 r/min
Calculation factor - kr:0.015
Calculation factor - f0:17
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.091
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Non-Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:55MM Bore; 72MM Outside Diameter; 9MM Outer Race Diameter; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:61811 2RZ
Weight / LBS:0.2
Outside Diameter:2.835 Inch | 72 Millimeter
Bore:2.165 Inch | 55 Millimeter
Outer Race Width:0.354 Inch | 9 Millimeter
bore diameter::55 mm
static load capacity::8.8 kN
outside diameter::72 mm
precision rating::Not Rated
overall width::9 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Double Sealed
outer ring width::9 mm
row type & fill slot::Single Row Non-Fill Slot
fillet radius::0.3 mm
internal clearance::C0
maximum rpm::9500 RPM
operating temperature range::-40 to +210 °F
series::61
dynamic load capacity::9.04 kN
d1 ≈:60.3 mm
D2 ≈:68.68 mm
r1,2 min.:0.3 mm
da min.:57 mm
da max.:60.5 mm
Da max.:70 mm
ra max.:0.3 mm
Basic dynamic load rating C:9.04 kN
Basic static load rating C0:8.8 kN
Fatigue load limit Pu:0.375 kN
Calculation factor kr:0.015
Calculation factor f0:17
Mass bearing:0.083 kg
