TIMKEN 109163D-2 - Leader Industrial Manufacture

✖

TIMKEN 109163D-2 image

Customers who bought this item also bought Roller Bearings

Rolling Element:Ball Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Non-expansion
Mounting Bolts:29/64 Inch
Relubricatable:Yes
Insert Part Number:G1015KRRB
Seals:Double Land Riding Rubber Contact
Housing Configuration:1 Piece Solid
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:2 Bolt Flange Block; 15/16" Bore; 3.9" Bolt Circle; 3-29/32" Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Iron; Ball Bearing; Relubricatable; Double Land Riding Rubber Cont
Other Features:Single Row | Normal Duty | With Set Screw
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.40
Noun:Bearing
Keyword String:Flanged
Manufacturer Item Number:RCJT 15/16
Weight / LBS:1.73
Bolt Spacing:3.906 Inch | 99.2 Millimeter
d:0.938 Inch | 23.825 Millimeter
D:0 Inch | 0 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round:3.9 Inch | 99 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Shaft Size d:15/16 in
Bearing Type:Ball Bearing
Bearing Number:G1015KRRB
Dimension E:1.839 in
Inside Ring Outside Diameter:0.941 in
e:0.072 in
Series:Industrial
Seal Type:Shroud Seal
Housing Width A:27.9 mm
Total Length H:123.8 mm
Total Height L:69.8 mm
Bolt Hole Spacing J:99.2 mm
Bolt Hole Size N:11.5 mm
Flange Thickness A1:11.1 mm
Center of Bearing from Housing End A2:0.778 mm
Inside Ring Width B:0 mm
Static Load Rating:1750 lbf
Dynamic Load Rating:3490 lbf
