Home>Products>Roller Bearings>NSK 23156CAME4C3 image

NSK 23156CAME4C3 image

Back to product page

Customers who bought this item also bought Roller Bearings

d1:131.2 mm
d2:131.2 mm
D1:163.8 mm
r1,2 - min.:2.1 mm
r3,4 - min.:1.1 mm
a:52.6 mm
da - min.:117 mm
db - min.:117 mm
Da - max.:178 mm
Db - max.:183 mm
ra - max.:2 mm
rb - max.:1 mm
dn:138.4 mm
Basic dynamic load rating - C:163 kN
Basic static load rating - C0:146 kN
Fatigue load limit - Pu:5.1 kN
Limiting speed for grease lubrication:7500 r/min
Limiting speed for oil lubrication:12000 mm/min
Ball - Dw:26.988 mm
Ball - z:15
Gref:48.333 cm3
Calculation factor - e:0.68
Calculation factor - Y2:1.41
Calculation factor - Y0:0.76
Calculation factor - X2:0.67
Calculation factor - Y1:0.92
Preload class A - GA:1000 N
Preload class B - GB:2000 N
Preload class C - GC:4000 N
Preload class D - GD:8000 N
Calculation factor - f:1.08
Calculation factor - f1:0.99
Calculation factor - f2A:1
Calculation factor - f2B:1.01
Calculation factor - f2C:1.03
Calculation factor - f2D:1.06
Calculation factor - fHC:1.01
Preload class A:342 N/micron
Preload class B:443 N/micron
Preload class C:585 N/micron
Preload class D:786 N/micron
r1,2 min.:2.1 mm
r3,4 min.:1.1 mm
da min.:117 mm
db min.:117 mm
Da max.:178 mm
Db max.:183 mm
ra max.:2 mm
rb max.:1 mm
Basic dynamic load rating C:163 kN
Basic static load rating C0:146 kN
Fatigue load limit Pu:5.1 kN
Attainable speed for grease lubrication:7500 r/min
Attainable speed for oil-air lubrication:12000 r/min
Ball diameter Dw:26.988 mm
Number of balls z:15
Reference grease quantity Gref:48.333 cm³
Preload class A GA:1000 N
Static axial stiffness, preload class A:342 N/µm
Preload class B GB:2000 N
Static axial stiffness, preload class B:443 N/µm
Preload class C GC:4000 N
Static axial stiffness, preload class C:585 N/µm
Preload class D GD:8000 N
Static axial stiffness, preload class D:786 N/µm
Calculation factor f:1.08
Calculation factor f1:0.99
Calculation factor f2A:1
Calculation factor f2B:1.01
Calculation factor f2C:1.03
Calculation factor f2D:1.06
Calculation factor fHC:1.01
Calculation factor e:0.68
Calculation factor (single, tandem) Y2:0.87
Calculation factor (single, tandem) Y0:0.38
Calculation factor (single, tandem) X2:0.41
Calculation factor (back-to-back, face-to-face) Y1:0.92
Calculation factor (back-to-back, face-to-face) Y2:1.41
Calculation factor (back-to-back, face-to-face) Y0:0.76
Calculation factor (back-to-back, face-to-face) X2:0.67
Mass bearing:3.14 kg
