TIMKEN 24076YMBW33W45A image

Back to product page

Customers who bought this item also bought Roller Bearings

C:33 mm
rn:0,5 mm
a:4,9 mm
b:3,1 mm
f:2,82 mm
r min.:2,1 mm
r0 max.:0,6 mm
D1:135,23 mm
D2:149,7 mm
da min.:76 mm
da max:86 mm
Da max.:129 mm
ra max.:2 mm
Dx:152 mm
Cy:7,3 mm
Cz:2,9 mm
Weight:2,08 Kg
Basic dynamic load rating (C):92,5 kN
Basic static load rating (C0):60 kN
(Grease) Lubrication Speed:4 900 r/min
(Oil) Lubrication Speed:5 800 r/min
a min:4.65 mm
a max:4.9 mm
Ca min:7.37 mm
Ca max:7.72 mm
rs min:2.1 mm
rNs min:0.5 mm
D3 max:135.23 mm
b min:3.1 mm
b max:3.4 mm
r0 max:0.6 mm
D4 max:149.7 mm
Snap ring reference:R140
Radial clearance class:CN
Mass:2.08 kg
Dynamic load, C:92.5 kN
Static load, C0:60 kN
Fatigue limit load, Cu:2.7 kN
f0:13.2
Nlim (oil):5,800 rpm
Nlim (grease):4,900 rpm
Min operating temperature, Tmin:-20 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.38 Hz
Characteristic rolling element frequency, BSF:4.07 Hz
Characteristic outer ring frequency, BPF0:3.07 Hz
Characteristic inner ring frequency, BPFI:4.93 Hz
da min:76 mm
Da max:129 mm
ra max:2 mm
rNa max:0.5 mm
Db min:152 mm
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:2.132
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:Yes
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:65MM Bore; 140MM Outside Diameter; 33MM Outer Race Width; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; Yes Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage
Other Features:Deep Groove | With Snap Ring
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6313NR
Weight / LBS:4.696
Outer Race Width:1.299 Inch | 33 Millimeter
Bore:2.559 Inch | 65 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Outside Diameter:5.512 Inch | 140 Millimeter
bore diameter::65 mm
precision rating::ISO Class 0
outside diameter::140 mm
finish/coating::Uncoated
overall width::33 mm
bearing material::High Carbon Chrome Steel
bore type::Round
cage material::Steel
closure type::Open
inner ring width::33 mm
row type & fill slot::Single Row Non-Fill Slot
outer ring width::33 mm
snap ring included::With Snap Ring
maximum rpm (grease)::4900 rpm
internal clearance::CN
maximum rpm (oil)::5800 rpm
operating temperature range::-40 to 120 ºC
fillet radius::2.1 mm
dynamic load capacity::92500 N
manufacturer product page::Click here
static load capacity::60000 N
