INA PAPZ1614P10 - Leader Industrial Manufacture

✖

INA PAPZ1614P10 image

INA PAPZ1614P10 Product Features

Mounting Method:Eccentric Collar
Rolling Element:Ball Bearing
Relubricatable:No
Seal Type:Double Land Riding Rubber Contact
Snap Ring:No
Inch - Metric:Inch
Long Description:1-15/16" Bore; Wide Inner Ring; 0.787" Outer Race Width; Cylindrical Outer Race Profile; 3.543" Outside Diameter; Eccentric Collar; Ball Bearing; 2-15/32" Length Thru Bore; No Relu
Other Features:Single Row | Standard Duty
D:2.469 Inch | 62.713 Millimeter
Outer Race Width:0.787 Inch | 19.99 Millimeter
d:1.938 Inch | 49.225 Millimeter
Shaft Size d:1 15/16 in
Bore Type:Cylindrical bore
Bearing Type:Ball Bearing
Material:Bearing Steel
Lubrication Type:Non-Relubricatable
O.D. Type:Cylindrical OD
Dimension B2:0.720 in
Series:Industrial
Sub Series:1..KRR
Outside Diameter D:3.543 in
Inner Ring Width B:49.21 mm
Outside Ring Width C:20.000 mm
Radius r:0.6 mm
Center of Bearing from End S:24.6 mm
Dimension S1:38.1 mm
Set Screw Size:3/8-16
Number of Set Screws:2
Angle between Set Screws:90 º
Dimension B1:2.469 in
Static Load Rating:5210 lbf
Dynamic Load Rating:8740 lbf
