KOYO 6811 ZZ - Leader Industrial Manufacture

✖

KOYO 6811 ZZ image

KOYO 6811 ZZ Characteristics

C:18 mm
r min.:1.1 mm
da min.:91 mm
Da max.:113 mm
ra max.:1.0 mm
Weight:0.517 Kg
Basic dynamic load rating (C):32 kN
Basic static load rating (C0):29,6 kN
(Grease) Lubrication Speed:5200 r/min
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.517
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:85MM Bore; 120MM Outside Diameter; 18MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Weight / LBS:1.14
Outer Race Width:0.709 Inch | 18 Millimeter
Bore:3.346 Inch | 85 Millimeter
Outside Diameter:4.724 Inch | 120 Millimeter
Bore Type:Cylindrical Bore
Configuration:Single Row
Bore Size:85 mm
Width:18 mm
Fillet Radius/Chamfer:1.1 mm
Dynamic Load Rating:32,000 N
Static Load Rating:29,600 N
Limiting Speed - Grease:5,400 rpm
Limiting Speed - Oil:6,300 rpm
Factor fo:16.4
Radial Clearance:0.012 to 0.036 mm
da (min):91 mm
Da (max):113 mm
ra (max):1 mm
