SKF 309SZZCG - Leader Industrial Manufacture

✖

SKF 309SZZCG image

SKF 309SZZCG Characteristics

UPC Code:0883450506021
Type E Open Cover Number:EUDR-3 15/16
Type E Closed Cover Number:EUC-I
Dimension B:6-1/4 in
Dimension L:15-1/4 in
Dimension A:4-1/2 in
Dimension J Min.:12-1/4 in
Dimension J Max.:12-3/4 in
Bolt Diameter:3/4 in
Dimension N:7/8 in
Dimension N1:1-1/8 in
Dimension N2:2-1/4 in
Dimension H1:2-7/16 in
Dimension H2:8-1/2 in
Dimension d1:6-1/16 in
Dimension H:4-1/4 in
Dimension Ac:7.25 in
Dimension d2:7.43 in
e:0.49
X (if Fa/Fr ≤ e):0.87
Y (if Fa/Fr ≤ e):1.77
X (if Fa/Fr > e):0.7
Y (if Fa/Fr > e):2.14
K Factor:1.23
C90 Dynamic Load Rating1:26900 lb
C0 Static Load Rating:154000 lb
Fa-max Maximum Permissible Thrust Load2:6908 lb
Fr-max Maximum Allowable Slip Fit Radial Load3:22000 lb
Max. Speed4:1530 rpm
Note:Note: All units have a 1/8 pipe thread grease fittingThe Maximum Permissible Thrust Load applies to conditions of slip fit with set screw mounting or in applications where a large moment loading occur
