TIMKEN 306WDD image

Back to product page

TIMKEN 306WDD Characteristics

d1:27.2 mm
D2:37.19 mm
r1,2 - min.:0.6 mm
da - min.:23.2 mm
da - max.:27.1 mm
Da - max.:38.8 mm
ra - max.:0.6 mm
Basic dynamic load rating - C:9.4 kN
Basic static load rating - C0:5 kN
Fatigue load limit - Pu:0.212 kN
Limiting speed:11000 r/min
Calculation factor - kr:0.025
Calculation factor - f0:14
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.098
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:20MM Bore; 42MM Outside Diameter; 16MM Outer Race Diameter; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
Other Features:Cartridge Bearing
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:63004-2RS1
Weight / LBS:0.216
Bore:0.787 Inch | 20 Millimeter
Outer Race Width:0.63 Inch | 16 Millimeter
Outside Diameter:1.654 Inch | 42 Millimeter
bore diameter::20 mm
static load capacity::5 kN
outside diameter::42 mm
precision rating::Not Rated
overall width::16 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Double Sealed
outer ring width::16 mm
row type & fill slot::Single Row Non-Fill Slot
fillet radius::0.6 mm
internal clearance::C0
maximum rpm::11000 RPM
operating temperature range::-40 to +210 °F
series::63
dynamic load capacity::9.36 kN
