TIMKEN 207W - Leader Industrial Manufacture

✖

TIMKEN 207W image

TIMKEN 207W Characteristics

C:15 mm
a:2,46 mm
b:1,5 mm
f:1,07 mm
r min.:1 mm
r0 max.:0,4 mm
r1 min.:0,5 mm
D1:49,73 mm
D2:57,9 mm
da min.:30 mm
Da max.:47 mm
Weight:0,128 Kg
Basic dynamic load rating (C):14 kN
Basic static load rating (C0):7,85 kN
(Grease) Lubrication Speed:13000 r/min
(Oil) Lubrication Speed:15000 r/min
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.143
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:Yes
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:25MM Bore; 52MM Outside Diameter; 15MM Outer Race Width; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; Yes Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage
Other Features:Deep Groove | With Snap Ring
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Weight / LBS:0.28219
Outside Diameter:2.047 Inch | 52 Millimeter
Outer Race Width:0.591 Inch | 15 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Bore:0.984 Inch | 25 Millimeter
Bearing No.:6205NR
r(min):1
r1(min):0.5
Cr:17.5
C0r:7.85
Cu:0.550
f0:13.9
Grease lub.:13000
Oil lub.:15000
D2(min):57.9
f(�}0.05):1.07
da(min):30
Da(max):47
Dx(min):58.5
Cy(max):3.33
ra(max):1
rb(max):0.5
(Refer.)Mass(kg):0.128
