SKF 1316/C3 - Leader Industrial Manufacture

✖

SKF 1316/C3 image

SKF 1316/C3 Characteristics

Number of Bearings:1 (Single)
Contact Angle:60 Degree
Preload:Heavy
Raceway Style:1 Rib Inner Ring and Outer Ring
Cage Material:Phenolic
Rolling Element:Ball Bearing
Mounting Arrangement:Universal
Flush Ground:Yes
Inch - Metric:Metric
Other Features:Single Row | Angular Contact Thrust Bearing | Ball Screw Support
Long Description:40MM Bore; 90MM Outside Diameter; 20MM Width; Open Enclosure; ABEC 7 | ISO P4 Precision; Steel Ball Material; 1 (Single) Bearings; 60 Degree Contact Angle; Phenolic Cage Material; 1 Rib Inner Ring and
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact Ball
Manufacturer Item Number:BST40X90-1BP4
D:3.543 Inch | 90 Millimeter
B:0.787 Inch | 20 Millimeter
d:1.575 Inch | 40 Millimeter
bore diameter::40 mm
radial dynamic load capacity::58500 N
outside diameter::90 mm
radial static load capacity::130000 N
overall width::15 mm
operating temperature range::-40 to 120 ºC
contact angle::60 °
cage material::Nylon
row type & fill slot::Single-Row Non-Fill Slot
finish/coating::Uncoated
internal clearance::C0
precision rating::ISO Class 4
bore type::Round
fillet radius::1 mm
closure type::Open
series::BST
snap ring included::Without Snap Ring
weight::0.631 kg
bearing material::High Carbon Chrome Steel
