SKF 71918 CDT/HCP4ADGA - Leader Industrial Manufacture

✖

Home>Products>Ball Bearings>SKF 71918 CDT/HCP4ADGA image

SKF 71918 CDT/HCP4ADGA image

SKF 71918 CDT/HCP4ADGA Characteristics

C:22 mm
r min.:1.1 mm
da min.:86 mm
Da max.:119 mm
ra max.:1.0 mm
Weight:0.855 Kg
Basic dynamic load rating (C):47,5 kN
Basic static load rating (C0):39,5 kN
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Product Group:B00308
Enclosure:2 Metal Shields
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:80MM Bore; 125MM Outside Diameter; 22MM Outer Race Width; 2 Metal Shields; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Ste
Other Features:Deep Groove
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Bore:3.15 Inch | 80 Millimeter
Outer Race Width:0.866 Inch | 22 Millimeter
Outside Diameter:4.921 Inch | 125 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Bore Type:Cylindrical Bore
Configuration:Single Row
Bore Size:80 mm
Width:22 mm
Fillet Radius/Chamfer:1.1 mm
Dynamic Load Rating:47,500 N
Static Load Rating:39,500 N
Limiting Speed - Grease:5,300 rpm
Factor fo:15.6
Radial Clearance:0.010 to 0.030 mm
da (min):86 mm
Da (max):119 mm
ra (max):1 mm
