NTN 7209CDB/GNP5 image

Back to product page

You Might Also Like

NTN 7209CDB/GNP5 Characteristics

UPC Code:0883450005524
Dimension BC:4.95 in
Dimension C:2.56 in
Dimension D:4.800 in
Dimension E:4.38 in
Dimension F:5.500 in
Dimension H:0.88 in
Dimension J (Bolt Size):0.5 in
Dimension M:1.21 in
Dimension N:2.560 in
Dimension S:1.98 in
C0 - Static Load:31900 lb
C - Dynamic Load (Basic):31400 lb
e - Geometry Factor:0.26
Y1 - Geometry Factor:2.64
Y2 - Geometry Factor:3.93
Oil Lubrication - M/N Seal:2200 rpm
Oil Lubrication - T Seal:3800 rpm
Oil Lubrication - B/C/O Seal:1800 rpm
Grease Lubrication - M/N Seal:2200 rpm
Grease Lubrication - T Seal:3200 rpm
Grease Lubrication - B/C/O Seal:1600 rpm
Float:0.050 in
Shaft Tolerance:0.0030 in
Pre Install Clearance Min:0.0030 in
Pre Install Clearance Max:0.0037 in
Int Radial Clearance Reduction Min:0.0012 in
Int Radial Clearance Reduction Max:0.0015 in
Adapter Sleeve Axial Movement Min:0.018 in
Adapter Sleeve Axial Movement Max:0.022 in
Post Install Int Radial Clearance Min:0.0015 in
