FAG BEARING QJ328-N2-MPA - Leader Industrial Manufacture

✖

Home>Products>Ball Bearings>FAG BEARING QJ328-N2-MPA image

FAG BEARING QJ328-N2-MPA image

FAG BEARING QJ328-N2-MPA Characteristics

Bore Profile:Tapered
Cage Material:Bronze
Enclosure:Open
Number of Rows of Rollers:Double Row
Relubricatable:Yes
Withdrawal Sleeve:AH3284 (Specify bore)
Inch - Metric:Metric
Long Description:420MM Tapered Bore; 760MM Outside Diameter; 272MM Width; C0-Medium Clearance; Adapter Mount; Double Row of Spherical Roller Bearings; Bronze Cage Material; Open Enclosure; Relubricatable; Adapter Part
Other Features:Order adapter or withdrawal sleeve or nut separately. Others may be available
UNSPSC:31171510
Harmonized Tariff Code:8482.30.80.00
Noun:Bearing
Keyword String:Spherical
Manufacturer Item Number:23284 KYMBW906A
Weight / LBS:525.4
d:16.535 Inch | 420 Millimeter
D:29.921 Inch | 760 Millimeter
B:10.709 Inch | 272 Millimeter
Adapter Part Number:SNP3284 (Specify bore) Inch | H3284 (Specify bore) Millimeter
Design Unit:METRIC
Bore Taper:1/12
Bearing Weight:541.000 Kg
Cage Type:YMB
UPC Code:087796188266
d - Bore:420.000 mm
D - Outer Diameter:760.000 mm
B - Inner Ring Width:272 mm
B - Outer Ring Width:272.000 mm
R - Inner Ring To Clear Radius1:6.000 mm
r - Outer Ring To Clear Radius2:6.000 mm
da - Inner Ring Backing Diameter:490.000 mm
Da - Outer Ring Backing Diameter:681.000 mm
C0 - Static Radial Rating:11800000 N
C1(2) - Dynamic Radial Rating (Two-Rows):7360000 N
e - ISO Factor3:0.35
Y0 - ISO Factor4:1.9
Y1 - ISO Factor5:2.83
Y2 - ISO Factor6:1.86
Reference Thermal Speed Rating (Grease):330
Reference Thermal Speed Rating (Oil)7:360
Cg - Geometry Factor8:0.0979
