(2 PCS) LM20UU (20mm) Linear Ball Bearing Bush Bushing CNC Unit For Mini Milling image

Back to product page

(2 PCS) LM20UU (20mm) Linear Ball Bearing Bush Bushing CNC Unit For Mini Milling Product identifiers

d1:83.3 mm
D2:105.8 mm
r1,2 - min.:1.5 mm
da - min.:74 mm
da - max.:83.2 mm
Da - max.:111 mm
ra - max.:1.5 mm
Basic dynamic load rating - C:60.5 kN
Basic static load rating - C0:58.5 kN
Fatigue load limit - Pu:2.5 kN
Reference speed:10000 r/min
Limiting speed:6000 r/min
Calculation factor - kr:0.04
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:1.139
Product Group:B00308
Enclosure:1 Metal Shield
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:Yes
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:65MM Bore; 120MM Outside Diameter; 23MM Outer Race Diameter; 1 Metal Shield; Ball Bearing; ABEC 1 | ISO P0; Yes Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:213 Z
Weight / LBS:2.49
Outside Diameter:4.724 Inch | 120 Millimeter
Bore:2.559 Inch | 65 Millimeter
Outer Race Width:0.906 Inch | 23 Millimeter
bore diameter::65 mm
static load capacity::58.5 kN
outside diameter::120 mm
precision rating::ABEC 1 (ISO Class Normal)
overall width::23 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Single Shield
outer ring width::23 mm
row type & fill slot::Single Row Filling Slot
fillet radius::1.5 mm
snap ring included::Without Snap Ring
maximum rpm::6000 RPM
internal clearance::C0
series::21
dynamic load capacity::60.5 kN
thrust application warning::This product can not be used in Thrust Applications
d1 ≈:83.3 mm
D2 ≈:105.8 mm
r1,2 min.:1.5 mm
da min.:74 mm
da max.:83.2 mm
Da max.:111 mm
ra max.:1.5 mm
Basic dynamic load rating C:60.5 kN
Basic static load rating C0:58.5 kN
Fatigue load limit Pu:2.5 kN
Calculation factor kr:0.04
Mass bearing:1.05 kg
