MDL-2_TR Standard Z Axis Bearing Housing CNC image

MDL-2_TR Standard Z Axis Bearing Housing CNC Product identifiers

Number of Bearings:2 (1 Pair)
Contact Angle:15 Degree
Preload:Light
Raceway Style:1 Rib Outer Ring
Cage Material:Nylon
Rolling Element:Ball Bearing
Mounting Arrangement:Duplex-Universal
Flush Ground:Yes
Inch - Metric:Metric
Other Features:Single Row | Angular Contact
Long Description:30MM Bore; 55MM Outside Diameter; 26MM Width; Open Enclosure; ABEC 7 | ISO P4 Precision; Steel Ball Material; 2 (1 Pair) Bearings; 15 Degree Contact Angle; Nylon Cage Material; 1 Rib Outer Ring Racewa
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact Ball
Manufacturer Item Number:7006CGD2/GNP4
Weight / LBS:0.491
B:1.024 Inch | 26 Millimeter
D:2.165 Inch | 55 Millimeter
d:1.181 Inch | 30 Millimeter
bore diameter::30 mm
precision rating::ISO Class 4
outside diameter::55 mm
cage material::Nylon
overall width::26 mm
finish/coating::Uncoated
contact angle::15 °
inner ring width::13 mm
duplex type::Universal Flush Ground
maximum rpm (oil)::34800 rpm
internal clearance::C0
maximum rpm (grease)::21760 rpm
closure type::Open
outer ring width::13 mm
operating temperature range::-40 to 120 ºC
fillet radius::1 mm
radial dynamic load capacity::3400 lb
series::70C
radial static load capacity::2310 lb
manufacturer product page::Click here
bearing material::High Carbon Chrome Steel
