THK GTR1210EC7S-540L Ground Ball Screw 12mm diameter 10mm lead NNB BSC-I-103 Code system

R - Cone Backface To Clear Radius3:0.14 in
da - Cone Frontface Backing Diameter:1.67 in
db - Cone Backface Backing Diameter:1.93 in
Ab - Cage-Cone Frontface Clearance:0.05 in
Aa - Cage-Cone Backface Clearance:0.04 in
a - Effective Center Location4:-0.34 in
C90 - Dynamic Radial Rating (90 million revolutions)5:6100 lbf
C1 - Dynamic Radial Rating (1 million revolutions)6:23500 lbf
C0 - Static Radial Rating:26800 lbf
Ca90 - Dynamic Thrust Rating (90 million revolutions)7:3820 lbf
K - Factor8:1.6
G1 - Heat Generation Factor (Roller-Raceway):29.9
G2 - Heat Generation Factor (Rib-Roller End):11.2
Cg - Geometry Factor:0.0781
