THK LINEAR GUIDE RAIL BEARING BLOCK SHS15C 4D073 2 1/2"

✖

Home>Products>Thk>THK LINEAR GUIDE RAIL BEARING BLOCK SHS15C 4D073 2 1/2" image

THK LINEAR GUIDE RAIL BEARING BLOCK SHS15C 4D073 2 1/2" image

THK LINEAR GUIDE RAIL BEARING BLOCK SHS15C 4D073 2 1/2" Code system

Seal Type:Double Land Riding Rubber Contact
Mounting Method:Eccentric Collar
Rolling Element:Ball Bearing
Snap Ring:No
Long Description:3/4" Bore; Narrow Inner Ring; Ball Bearing; 1-7/32" Length Thru Bore; 0.551" Outer Race Width; 1.85" Outside Diameter; Relubricatable; Double Land Riding Rubber Contact Seal; Eccen
Inch - Metric:Inch
Other Features:Single Row | Standard Duty
UNSPSC:31171536
Harmonized Tariff Code:8482.10.50.00
Noun:Bearing
Keyword String:Insert
Manufacturer Item Number:GRA012RRB AG
Weight / LBS:0.29
d:0.75 Inch | 19.05 Millimeter
D:1.219 Inch | 30.963 Millimeter
Outer Race Width:0.551 Inch | 13.995 Millimeter
Shaft Size d:3/4 in
Bore Type:Cylindrical bore
Bearing Type:Ball Bearing
Material:Bearing Steel
Lubrication Type:Relubricatable
O.D. Type:Spherical OD
Dimension M:0.120 in
Dimension B2:0.531 in
Series:Standard
Sub Series:GRA..RRB
Outside Diameter D:1.850 in
Inner Ring Width B:21.44 mm
Outside Ring Width C:14.000 mm
Radius r:0.6 mm
Center of Bearing from End S:7.49 mm
Dimension S1:23.51 mm
Set Screw Size:1/4-20
Number of Set Screws:2
Angle between Set Screws:90 º
Dimension B1:1.220 in
Static Load Rating:1460 lbf
Dynamic Load Rating:3190 lbf
