WHEEL BEARING KIT VW PASSAT Estate (32B) 1.8 90BHP Top German Quality

✖

Home>Products>snr bearing>WHEEL BEARING KIT VW PASSAT Estate (32B) 1.8 90BHP Top German Quality image

WHEEL BEARING KIT VW PASSAT Estate (32B) 1.8 90BHP Top German Quality image

WHEEL BEARING KIT VW PASSAT Estate (32B) 1.8 90BHP Top German Quality Systems

Rolling Element:Ball Bearing
Snap Ring:Yes
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:45MM Bore; 85MM Outside Diameter; 19MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; Yes Filling Slot; Yes Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:209 NR
Weight / LBS:1.01
d:45 mm
Outer Race Width:0.748 Inch | 19 Millimeter
D:85 mm
bore diameter::45 mm
static load capacity::30 kN
outside diameter::85 mm
precision rating::ABEC 3 (ISO Class 6)
overall width::19 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Open
outer ring width::19 mm
row type & fill slot::Single Row Filling Slot
fillet radius::1 mm
snap ring included::With Snap Ring
maximum rpm::8500 RPM
internal clearance::C0
series::20
dynamic load capacity::35.2 kN
thrust application warning::This product can not be used in Thrust Applications
B:19 mm
d1 ≈:57.6 mm
D2 ≈:75.19 mm
D3:81.81 mm
b:1.9 mm
C:3.28 mm
f:1.7 mm
r0 max.:0.6 mm
r1,2 min.:1.1 mm
da min.:52 mm
Da max.:78 mm
Db min.:93 mm
ba min.:2.2 mm
Ca max.:4.98 mm
ra max.:1 mm
Basic dynamic load rating C:35.2 kN
Basic static load rating C0:30 kN
Fatigue load limit Pu:1.27 kN
Reference speed:14000 r/min
Limiting speed:8500 r/min
Calculation factor kr:0.04
Snap ring:SP 85
