THK 5" Precision Linear Block Slider Rail Block 1.20" L .80" W .30" H A7A11 947

✖

Home>Products>Thk>THK 5" Precision Linear Block Slider Rail Block 1.20" L .80" W .30" H A7A11 947 image

THK 5" Precision Linear Block Slider Rail Block 1.20" L .80" W .30" H A7A11 947 image

THK 5" Precision Linear Block Slider Rail Block 1.20" L .80" W .30" H A7A11 947 Code system

Mounting Method:Eccentric Collar
Rolling Element:Ball Bearing
Relubricatable:No
Seal Type:Double Land Riding Rubber Contact
Snap Ring:No
Inch - Metric:Inch
Long Description:1-7/16" Bore; Wide Inner Ring; 0.669" Outer Race Width; Cylindrical Outer Race Profile; 2.835" Outside Diameter; Eccentric Collar; Ball Bearing; 2-1/64" Length Thru Bore; No Relubr
Other Features:Single Row | Standard Duty
d:1.438 Inch | 36.525 Millimeter
D:2.016 Inch | 51.206 Millimeter
Outer Race Width:0.669 Inch | 16.993 Millimeter
Shaft Size d:1 7/16 in
Bore Type:Cylindrical bore
Bearing Type:Ball Bearing
Material:Bearing Steel
Lubrication Type:Non-Relubricatable
O.D. Type:Cylindrical OD
Dimension B2:0.673 in
Series:Industrial
Sub Series:1..KRR
Outside Diameter D:2.835 in
Inner Ring Width B:37.7 mm
Outside Ring Width C:17.000 mm
Radius r:0.6 mm
Center of Bearing from End S:18.85 mm
Dimension S1:32.35 mm
Set Screw Size:3/8-16
Number of Set Screws:2
Angle between Set Screws:90 º
Dimension B1:2.016 in
Static Load Rating:3440 lbf
Dynamic Load Rating:6400 lbf
