Wheel Bearing and Hub Assembly Rear TIMKEN 512012

✖

Home>Products>timken bearing>Wheel Bearing and Hub Assembly Rear TIMKEN 512012 image

Wheel Bearing and Hub Assembly Rear TIMKEN 512012 image

Wheel Bearing and Hub Assembly Rear TIMKEN 512012 Sponsored Products Related To This Item

Seal Type:Double Land Riding Rubber Contact
Mounting Method:Eccentric Collar
Rolling Element:Ball Bearing
Snap Ring:No
Long Description:1-1/4" Bore; Wide Inner Ring; Ball Bearing; 1-29/32" Length Thru Bore; 0.709" Outer Race Width; 2.441" Outside Diameter; Not Relubricatable; Double Land Riding Rubber Contact Seal;
Inch - Metric:Inch
Other Features:Single Row | Standard Duty
UNSPSC:31171536
Harmonized Tariff Code:8482.10.50.00
Noun:Bearing
Keyword String:Insert
Manufacturer Item Number:1103KRRB3 AG
Weight / LBS:0.77
d:1.25 Inch | 31.75 Millimeter
Outer Race Width:0.709 Inch | 18.009 Millimeter
D:2.441 Inch | 62.001 Millimeter
Shaft Size d:1 1/4 in
Bore Type:Cylindrical bore
Bearing Type:Ball Bearing
Material:Bearing Steel
Lubrication Type:Non-Relubricatable
O.D. Type:Spherical OD
Dimension B2:0.626 in
Series:Industrial
Sub Series:1..KRRB
Outside Diameter D:2.441 in
Inner Ring Width B:36.51 mm
Outside Ring Width C:18.000 mm
Radius r:0.6 mm
Center of Bearing from End S:18.3 mm
Dimension S1:30.1 mm
Set Screw Size:5/16-18
Number of Set Screws:2
Angle between Set Screws:90 º
Dimension B1:1.906 in
Static Load Rating:2530 lbf
Dynamic Load Rating:4850 lbf
