VEX 65 7CE1 SNFA 65x100x18mm Basic dynamic load rating (C) 20.3 kN Angular contact ball bearings

✖

Home>Products>Angular contact ball bearings>VEX 65 7CE1 SNFA 65x100x18mm Basic dynamic load rating (C) 20.3 kN Angular contact ball bearings image

VEX 65 7CE1 SNFA 65x100x18mm Basic dynamic load rating (C) 20.3 kN Angular contact ball bearings image

The details of Angular contact ball bearings

C:21 mm
a:3.28 mm
b:1.9 mm
f:1.6 mm
r min.:1.5 mm
r1 min.:0.5 mm
D1:76.81 mm
D2:86.6 mm
Weight:0.457 Kg
Basic dynamic load rating (C):33,5 kN
Basic static load rating (C0):19,1 kN
(Grease) Lubrication Speed:8400 r/min
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Product Group:B00308
Enclosure:1 Metal Shield
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:Yes
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:35MM Bore; 80MM Outside Diameter; 21MM Outer Race Width; 1 Metal Shield; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; Yes Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Stee
Other Features:Deep Groove | With Snap Ring
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Bore:1.378 Inch | 35 Millimeter
Outer Race Width:0.827 Inch | 21 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Outside Diameter:3.15 Inch | 80 Millimeter
Bore Type:Cylindrical Bore
Configuration:Single Row
Bore Size:35 mm
Width:21 mm
Fillet Radius/Chamfer:1.5 mm
r1:0.5 mm
Snap Ring Width:1.6 mm
Snap Ring Outside Diameter:86.6 mm
D1 (max):76.8 mm
a (max):3.3 mm
b (min):1.9 mm
Dynamic Load Rating:33,500 N
Static Load Rating:19,100 N
Limiting Speed - Grease:8,800 rpm
Limiting Speed - Oil:10,000 rpm
Factor fo:13.2
Radial Clearance:0.006 to 0.020 mm
da (min):44 mm
Da (max):71 mm
Dx (min):88 mm
ra (max):1.5 mm
Cy (max):4.6 mm
