S71919 ACD/P4A SKF 130x95x18mm  Ball – z 28 Angular contact ball bearings

S71919 ACD/P4A SKF 130x95x18mm Ball – z 28 Angular contact ball bearings

Bearing numberS71919 ACD/P4ASize (mm)130x95x18BrandSKFBore Diameter (mm)130Outer Diameter (mm)95Width (mm)18d95 mmD130 mmB18 mmd1105.8 mmd2105.8 mmD2122.18 mmr1,2 - min.1.1 mmr3,4 - min.0.6 mma35.3 mmda - min.101 mmda - max.105.2 mmdb - min.101 mmdb - max.105.2 mmDa - max.124 mmDb - max.126 mmra - max.1 mmrb - max.0.6 mmBasic dynamic load rating - …
Contact Us Now !

Product description

S71919 ACD/P4A SKF 130x95x18mm Ball – z 28 Angular contact ball bearings

Bearing numberS71919 ACD/P4A
Size (mm)130x95x18
BrandSKF
Bore Diameter (mm)130
Outer Diameter (mm)95
Width (mm)18
d95 mm
D130 mm
B18 mm
d1105.8 mm
d2105.8 mm
D2122.18 mm
r1,2 – min.1.1 mm
r3,4 – min.0.6 mm
a35.3 mm
da – min.101 mm
da – max.105.2 mm
db – min.101 mm
db – max.105.2 mm
Da – max.124 mm
Db – max.126 mm
ra – max.1 mm
rb – max.0.6 mm
Basic dynamic load rating – C46.2 kN
Basic static load rating – C052 kN
Fatigue load limit – Pu2.1 kN
Limiting speed for grease lubrication8500 r/min
Ball – Dw11.112 mm
Ball – z28
Calculation factor – e0.68
Calculation factor – Y20.87
Calculation factor – Y00.38
Calculation factor – X20.41
Calculation factor – Y10.92
Calculation factor – Y21.41
Calculation factor – Y00.76
Calculation factor – X20.67
Preload class A – GA290 N
Preload class B – GB580 N
Preload class C – GC1160 N
Preload class D – GD2320 N
Calculation factor – f1.26
Calculation factor – f10.98
Calculation factor – f2A1
Calculation factor – f2B1.04
Calculation factor – f2C1.08
Calculation factor – f2D1.14
Calculation factor – fHC1
Preload class A240 N/micron
Preload class B315 N/micron
Preload class C420 N/micron
Preload class D576 N/micron
d1105.8 mm
d2105.8 mm
D2122.18 mm
r1,2 min.1.1 mm
r3,4 min.0.6 mm
da min.101 mm
da max.105.2 mm
db min.101 mm
db max.105.2 mm
Da max.124 mm
Db max.126 mm
ra max.1 mm
rb max.0.6 mm
Basic dynamic load rating C46.2 kN
Basic static load rating C052 kN
Fatigue load limit Pu2.08 kN
Attainable speed for grease lubrication8500 r/min
Ball diameter Dw11.112 mm
Number of balls z28
Preload class A GA290 N
Static axial stiffness, preload class A240 N/µm
Preload class B GB580 N
Static axial stiffness, preload class B315 N/µm
Preload class C GC1160 N
Static axial stiffness, preload class C420 N/µm
Preload class D GD2320 N
Static axial stiffness, preload class D576 N/µm
Calculation factor f1.26
Calculation factor f10.98
Calculation factor f2A1
Calculation factor f2B1.04
Calculation factor f2C1.08
Calculation factor f2D1.14
Calculation factor fHC1
Calculation factor e0.68
Calculation factor (single, tandem) Y20.87
Calculation factor (single, tandem) Y00.38
Calculation factor (single, tandem) X20.41
Calculation factor (back-to-back, face-to-face) Y10.92
Calculation factor (back-to-back, face-to-face) Y21.41
Calculation factor (back-to-back, face-to-face) Y00.76
Calculation factor (back-to-back, face-to-face) X20.67
Mass bearing0.6 kg
