S71928 ACD/P4A SKF 190x140x24mm  Calculation factor – f 1.29 Angular contact ball bearings

S71928 ACD/P4A SKF 190x140x24mm Calculation factor – f 1.29 Angular contact ball bearings

Bearing numberS71928 ACD/P4ASize (mm)190x140x24BrandSKFBore Diameter (mm)190Outer Diameter (mm)140Width (mm)24d140 mmD190 mmB24 mmd1155.4 mmd2155.4 mmD2178.25 mmr1,2 - min.1.5 mmr3,4 - min.0.6 mma50.6 mmda - min.147 mmda - max.154.8 mmdb - min.147 mmdb - max.154.8 mmDa - max.183 mmDb - max.186 mmra - max.1.5 mmrb - max.0.6 mmBasic dynamic load rati…
Contact Us Now !

Product description

S71928 ACD/P4A SKF 190x140x24mm Calculation factor – f 1.29 Angular contact ball bearings

Bearing numberS71928 ACD/P4A
Size (mm)190x140x24
BrandSKF
Bore Diameter (mm)190
Outer Diameter (mm)140
Width (mm)24
d140 mm
D190 mm
B24 mm
d1155.4 mm
d2155.4 mm
D2178.25 mm
r1,2 – min.1.5 mm
r3,4 – min.0.6 mm
a50.6 mm
da – min.147 mm
da – max.154.8 mm
db – min.147 mm
db – max.154.8 mm
Da – max.183 mm
Db – max.186 mm
ra – max.1.5 mm
rb – max.0.6 mm
Basic dynamic load rating – C90.4 kN
Basic static load rating – C0110 kN
Fatigue load limit – Pu3.6 kN
Limiting speed for grease lubrication6000 r/min
Ball – Dw15.875 mm
Ball – z29
Calculation factor – e0.68
Calculation factor – Y20.87
Calculation factor – Y00.38
Calculation factor – X20.41
Calculation factor – Y10.92
Calculation factor – Y21.41
Calculation factor – Y00.76
Calculation factor – X20.67
Preload class A – GA560 N
Preload class B – GB1120 N
Preload class C – GC2240 N
Preload class D – GD4480 N
Calculation factor – f1.29
Calculation factor – f10.98
Calculation factor – f2A1
Calculation factor – f2B1.04
Calculation factor – f2C1.08
Calculation factor – f2D1.14
Calculation factor – fHC1
Preload class A348 N/micron
Preload class B457 N/micron
Preload class C614 N/micron
Preload class D841 N/micron
d1155.4 mm
d2155.4 mm
D2178.25 mm
r1,2 min.1.5 mm
r3,4 min.0.6 mm
da min.147 mm
da max.154.8 mm
db min.147 mm
db max.154.8 mm
Da max.183 mm
Db max.186 mm
ra max.1.5 mm
rb max.0.6 mm
Basic dynamic load rating C90.4 kN
Basic static load rating C0110 kN
Fatigue load limit Pu3.65 kN
Attainable speed for grease lubrication6000 r/min
Ball diameter Dw15.875 mm
Number of balls z29
Preload class A GA560 N
Static axial stiffness, preload class A348 N/µm
Preload class B GB1120 N
Static axial stiffness, preload class B457 N/µm
Preload class C GC2240 N
Static axial stiffness, preload class C614 N/µm
Preload class D GD4480 N
Static axial stiffness, preload class D841 N/µm
Calculation factor f1.29
Calculation factor f10.98
Calculation factor f2A1
Calculation factor f2B1.04
Calculation factor f2C1.08
Calculation factor f2D1.14
Calculation factor fHC1
Calculation factor e0.68
Calculation factor (single, tandem) Y20.87
Calculation factor (single, tandem) Y00.38
Calculation factor (single, tandem) X20.41
Calculation factor (back-to-back, face-to-face) Y10.92
Calculation factor (back-to-back, face-to-face) Y21.41
Calculation factor (back-to-back, face-to-face) Y00.76
Calculation factor (back-to-back, face-to-face) X20.67
Mass bearing1.69 kg
